General Inspection

When you get a new DS1000E, DS1000D series oscilloscope, please inspect the
instrument according to the following steps:
1. Inspect the shipping container for damage.
Keep a damaged shipping container and cushioning material until the contents of
the shipment have been checked for completeness and the instrument has been
checked mechanically and electrically.
2. Inspect the instrument.
In case there is any mechanical damage or defect, or the instrument does not
operate properly or fails performance tests, please notify the RIGOL Sales
Representative.
If the shipping container is damaged, or the cushioning materials show signs of
stress, please notify the carrier as well as the RIGOL sales office. Keep the
shipping materials for the carrier's inspection. RIGOL offices will arrange for
repair or replacement at RIGOL's option without waiting for claim settlement.
3. Check the accessories.
Accessories supplied with the instrument are listed below. If the contents are
incomplete or damaged, please notify the RIGOL Sales Representative.
Standard Accessories:
Probe×2 (1.5m), (1:1 or 10:1 adjustable) Passive Probes

The passive probes have a 6MHz bandwidth with a rating of 150V CAT II
when the switch is in the 1X position, and a Full oscilloscope bandwidth with
a rating of 300 V CAT II when the switch is in the 10X position.
A Power Cord that fits the standard of destination country

An USB Cable

A Logic Cable (only for DS1000D series)

An active logic head (only for DS1000D series)

20 Logic Testing Nips (only for DS1000D series)

20 Logic Testing Leads (only for DS1000D series)

A CD-ROM (including "User's Guide" and Application Software)

A Quick Guide

