Chapter 3 Performance Test

Specifications Test

This section introduces the performance verification test method of
DS1000E/DS1000D series digital oscilloscope by taking DS1102E as an example. You
can perform the following test in any order. In this manual, the test device used is
Fluke 9500B. You can also use other devices that fulfill the specification requirements
for the test.
Recommended Devices List:
Device
Oscilloscope
Calibrator
Digital
Multimeter
Test Cable
Signal Generator Frequency Accuracy: ±1 ppm
Test Cable
Note:
1) Make sure that the oscilloscope passes the self-calibration before performing the
performance calibration test.
2) Make sure that the oscilloscope has been warmed up for 30 minutes before
executing any of the following tests.
3) Please reset the instrument to the factory setting before or after executing any of
the following tests.
Service Guide for DS1000E, DS1000D Series
Specification
Output range of DC voltage:
1 MΩ: 1 mV to 200 V
50 MΩ：1 mV to 200 V
The rise time of fast edge signal: ≤ 150
ps
The resistance measurement accuracy is
higher than ±0.1% of reading
BNC (male) to Dual-banana Plug Cable
BNC (m)-BNC (m) cable
RIGOL
Recommended
Model
Fluke 9500B
RIGOL DM3058/3068
--
RIGOL DG4162
--
