RIGOL
Test Record Form:
Channel
Vertical Scale
100 mV/div
CH1
200 mV/div
500 mV/div
100 mV/div
CH2
200 mV/div
500 mV/div
[1]
Note
: amplitude loss (dB) = 20×lg
3-16
Test Result
Vrms1
Vrms2
Amplitude
[1]
Loss
Vrms1
Vrms2
Amplitude Loss
Vrms1
Vrms2
Amplitude Loss
Vrms1
Vrms2
Amplitude Loss
Vrms1
Vrms2
Amplitude Loss
Vrms1
Vrms2
Amplitude Loss
(Vrms2/Vrms1)
.
Service Guide for DS1000E, DS1000D Series
Chapter 3 Performance Test
Limit
Pass/Fail
≥ -3 dB and ≤ 1
dB
