Specifications

Acquisition
Sampling Modes
Sampling Rate
Averages
Inputs
Input Coupling
Input Impedance
Probe Attenuation Factors
Maximum Input Voltage
Time delay between channel
(typical)
Horizontal
Sample Rate
Range
Waveform
interpolation
Record Length
Scan speed Range
(Sec/div)
Sample Rate and
Delay Time
Accuracy
Delta Time
Measurement
Accuracy
(Full Bandwidth)
Vertical
1-2
Real-Time
[1]
1GSa/s , 500MSa/s
N time acquisitions, all channels simultaneously, N is
selectable from 2, 4, 8, 16, 32, 64, 128 and 256.
DC, AC, GND
1MΩ±2%
18pF±3pF
1X, 5X, 10X, 50X, 100X, 500X,1000X
400V (DC＋AC Peak, 1MΩ input impedance)
40V (DC+AC Peak)
500ps
Real-Time: 13.65Sa/s-1GSa/s
Equivalent: 13.65Sa/s-25GSa/s
Sin(x)/x
Channel Mode
Single channel
Single channel
Double channel
Double channel
2ns/div~50s/div, DS1102X
5ns/div~50s/div, DS1052X
1-2-5 Sequence
±50ppm (over any 1ms time interval)
Single-shot: ±(1 sample interval + 50ppm × reading + 0.6 ns)
>16 averages: ±(1sample interval + 50ppm × reading + 0.4
ns)
Equivalent
DS1102X
25GSa/s
[1]
Sample rate Record
Length
(normal)
1GSa/s 16kpts
500MSa/s 16kpts
Or lower
500MSa/s 8kpts
Or lower
250MSa/s 8kpts
Or lower
Service Guide for DS1000E, DS1000D Series
Chapter 1 Specifications
DS1052X
10GSa/s
Record
Length
(long record)
N.A.
1Mpts
N.A.
512kpts
