Alternate Trigger - Rigol DS1102E Datasheet

Trigger Condition
Pulse Width Range
Video Trigger
Video Standard
Line Frequency
Slope Trigger
Trigger Condition
Time Setting

Alternate Trigger

Trigger on CH1
Trigger on CH2
[2]
Pattern Trigger
Pattern Type
[2]
Duration Trigger
Pattern Type
Qualifier
Time Setting
Measurements
Cursor
Auto Measure
Remarks:
[1] Only one channel is available when the Sample rate is 1GSa/s.
[2] For DS1000D Series.
(＞, ＜, =) Positive pulse width, (＞, ＜, =) Negative pulse width
20ns ~10s
Support for standard NTSC, PAL and SECAM broadcast systems. Line
number range: 1~525 (NTSC) and 1~625 (PAL/SECAM)
(＞, ＜, =) Positive slope, (＞, ＜, =) Negative slope
20ns~10s
Edge, Pulse Width, Video, Slope
Edge, Pulse Width, Video, Slope
D0~D15 select H, L, X,
D0~D15 select H, L, X
＞, ＜, =
20ns~10s
Voltage difference between cursors (∆V)
Manual Time difference between cursors (∆T)
Reciprocal of ∆T in Hertz (1/∆T)
Voltage value for Y-axis waveform
Track
Time value for X-axis waveform
Auto Cursors are visible for Automatic Measurement
Vpp, Vamp, Vmax, Vmin, Vtop, Vbase, Vavg, Vrms, Overshoot, Preshoot, Freq,
Period, Rise Time, Fall Time, +Width, -Width, +Duty, -Duty, Delay1→2 ,
Delay1→2
,
4
