Option
Number_of_APDU_
Retries
Send Test Alarms
Clear Test Alarms
Table 4.13

4.3.15 Alarm Management

Use this page to manage and reset current alarms, messages, and alarm history.
Figure 4.32
Option
Silence Audible
Alarms
Reset Leak Alarm
Acknowledge
Preventative
Maintenance Alarm
Clear Alarm History
Acknowledge
Unsent Emails
Acknowledge Snmp
Informs
Table 4.14
rletech.com
Description
The maximum number of times and APDU is retransmitted.
Click this button to test your alarm configuration. Press the submit
changes button before clicking this link, or all your BACnet
configuration data will be lost.
Click this button to clear the test alarms once they have been sent
and correctly received.
Bacnet Options
Alarm Management Page
Description
Click to silence the current audible alarm. This will not turn off the
audible alarm permanently - that option is available on the Leak
page.
Resets the current leak alarm and causes the LD5200 to recheck the
current cable conditions. This clears the alarm condition if the cable
registers that the leak threshold is within an accepted range.
The preventative maintenance alarm is configured on the Leak page.
Use this link to acknowledge the alarm once it is activated.
View the alarm history through the Historical Data link at the top of
the web interface. Click this button to clear the alarm history of all
previous alarms.
Clears unsent emails so they aren't sent to recipients. Events are still
logged in the historical data.
Acknowledges SNMP Informs and stops Informs from being sent out
for the current alarm condition.
Alarm Management Options
LD5200 User Guide
4 Web Interface
81
