4 Web Interface
Option
Map Alarm
Coordinates -
Graphical
Map Alarm Test
User Image File
Delete Image #
Table 4.7
Several options on this page fall above the gray line that separates the image upload section of
the page. If you edit any of the fields above the line, be sure to press the Submit Changes
button to save your edits before you upload an image. If you click the Upload button without
submitting your changes, all your edits will be lost.

4.3.8.1 Upload the Map Image

From the Map Configuration page, click the Browse or Choose File button. Depending on
1
which browser you're using, this button may have different names.
64
Description
Use this link to designate mapped points with the uploaded image.
Click this link to view a test map, with all mapped points displayed
in their alarm state.
This non-editable field reports the name and size of the image
currently uploaded.
Use this button to delete the uploaded image.
Click the Browse or Choose File button to locate the prepared floor
map on your system.
Acceptable file formats: .jpeg, .jpg, .bmp, .png, and .gif. .pdf and
.vsd files can be uploaded for reference, but cannot support
interactive mapping capabilities.
File size: less than 500kb
Maximum physical size: 4000x4000 pixels
Select the correct file and click the Upload button to load the file
onto the LD5200.
Map Settings Options
LD5200 User Guide 800.518.1519
