4 Web Interface

4.3.5 Network/IP

The Network/IP page displays the assigned MAC address and allows users to configure
common network information. Editing this information will change the way the web interface
operates. Only change this information if you have been in contact with your network
administrator, and are sure the changes are correct.
Figure 4.10
Option
MAC Address
IP Address
Net Mask
Def Route
Http Port
Tcp Max Seg Size
Disable Network
Watchdog
Table 4.5
58
Network/IP Configuration Page
Description
The MAC address is a unique identifier set by the manufacturer,
and is non-editable.
Set the IP address for the LD5200, so it can communicate on your
network. If you do not have an IP address for the device, obtain one
from your IT department.
Default IP address: 10.0.0.188
Designate the device's Subnet Mask. Contact your IT department
for further information.
Default subnet mask: 255.255.255.0
Designate the device's default route (default gateway). If you do not
have a default route, obtain one from your IT department.
Default device route: 10.0.0.1
Some ISPs use alternate http ports as an added security measure.
Edit this field in accordance with your ISPs security settings.
Default: 0 = Port 80
The LD5200 defaults to 1436 packet size for web page data. Users
may select 536 for limited bandwidth or VPN applications.
Default: 1436
The network watchdog is used to reboot the device if excessive
network traffic or errors are detected.
Default: No
Network/IP Configuration Options
LD5200 User Guide 800.518.1519
