Page 1 LD5200 User Guide Version 2.6 Firmware Version 2.2.15...
Page 2 Raymond & Lae Engineering, Inc. are subject to the limited warranty, limited liability, and other terms and conditions of sale set forth at http://www.rletech.com/. Revision History Rev. No. Date April 2011 April 2012 May 2012 July 2013 April 2014 September 2015 November 2016 December 2016 LD5200 User Guide 800.518.1519...
Page 3 Product Serial Number Product Manufacture Date The LD5200 is not a field-serviceable item and must be sent back to RLE Technologies for mechanical repair. Power must be disconnected (unplugged) from the LD5200 any time the unit is mechanically serviced. Physically unplug power from the unit any time you are making wiring connections to or from the LD5200.
Page 4 Purchaser has ordered a product conforming to Purchaser’s specifications, or conforming to Purchaser’s specific design. Purchaser has not relied and shall not rely on any oral representation regarding the Product sold hereunder and any oral representation shall not bind Seller and shall not be part of any warranty. LD5200 User Guide 800.518.1519...
Page 5: Table Of Contents
Apply Power to the LD5200 ........
Page 6 Connect Distance Read Panels to the LD5200 ........
Page 7 Troubleshooting Problems with the LD5200 ........
Page 8 LD5200 User Guide 800.518.1519...
Page 9 Figure 4.1 LD5200 Web Interface Home Page ....... . . 47 Figure 4.2...
Page 10 Figure 5.1 LD5200 Connection Diagram ........
Page 11 Exception Codes ..........89 rletech.com LD5200 User Guide...
Page 12 Troubleshooting ..........111 Table D.1 Troubleshoot Problems with the LD5200 ......111 Table D.2 Troubleshoot Sensing Cable.
Page 13: Product Overview
An audible alarm sounds. ♦ The distance to the leak is shown on the LD5200’s LCD touch screen and on the LD5200’s web interface. An integrated reference map within the web interface will also show the location of the leak.
Page 14: Distance-Read Leak Detection
This web interface can be used on site or remotely via network communications. Digital fault and leak relay outputs and a 4-20mA relay output and allow the LD5200 to interface with third-party management systems. The LD5200 also provides Modbus outputs via EIA-485, twisted-pair wire, or TCP/IP, as well as BACnet/IP or BACnet/MSTP, SNMP, and SMTP outputs.
Page 15: Installation
Prepare for Installation Before you install or troubleshoot equipment, always check the RLE website first to ensure you’re working with the most recent version of our documentation. To install the LD5200, you’ll need the following supplies: Included with the LD5200 ♦...
Page 16: Mount The Ld5200
The LD5200 is built with two circuit boards: ♦ The display board is mounted on the inside of the LD5200’s door, and is connected to the main board with a multi-wire connector. The display is a color touch screen that enables configuration and management from the front panel.
Page 17: Figure 2.2 Ld5200 Physical Connections And Switches
(2) Form C Fault Relay Outputs TB3 - Form C Maintenance Relay TB2 - Cable Interface (W-B-G-R) TB1 - 4-20mA Output SA1 - Audible Alarm J4 - LCD Connection Figure 2.2 LD5200 Physical Connections and Switches rletech.com LD5200 User Guide...
Page 18: Tb1: 4-20Ma Output
A 15-foot (4.57m) section of non-sensing cable is supplied with each LD5200. The leader cable connects sensing cable to the LD5200, since sensing cable cannot connect directly to the unit. Insert its four stripped wires into the appropriate slots in TB2 - from left to right: white, black, green and red.
Page 19: P1: Eia-232 Connector
The switch position numbered 2 on SW1, when switched on (down position), places a termination resistor across the + and - terminals of the EIA-485 port. This is used when the TB5 connection on the LD5200 is the last unit on a EIA-485 network. SW1, switch position 1, is currently inactive.
Page 20: Sw2: Tb6 Port 2 (Bottom Row) Termination Switch
The switch position numbered 2 on SW3, when switched on (down position), places a termination resistor across the + and - terminals of the EIA-485 port. This is used when the TB6 (top row) connection on the LD5200 is the last unit on a EIA-485 network. SW3, switch position 1, is currently inactive.
Page 21: Connect The Seahawk Sensing Cable
To avoid faulty leak detection readings, connect a minimum length of 35 feet (10.7m) of sensing cable to the LD5200. The LD5200 is shipped with a 15-foot (4.57m) leader cable. This leader cable was connected to the LD5200 in Section 2.3.2 on page 18.
Page 22: Apply Power To The Ld5200
J-clips 3 feet (0.91m) apart. Figure 2.5 Secure the Cable Apply Power to the LD5200 A dedicated circuit breaker must be provided within close proximity to the LD5200 and be clearly marked as the disconnecting device for the LD5200 leak detection controller. ARNING Do not connect 120/230 VAC directly to the unit, or damage will occur to the circuitry.
Page 23: Configure Communications
Push the Setup button on the LD5200’s LCD. You’ll be prompted to enter a password. By default, there is no password on the LD5200. To continue past the login screen, leave the password field blank and press the Enter button You can establish an LCD password through either the LCD interface (“Leak Settings”...
Page 24: Test The System
Installation Test the System If the LD5200 is already connected to a BMS or NMS, notify monitoring personnel before you Note begin testing the system. Using a sketch or mechanical drawing of the facility, add the cable routing, connection points, and any accessories used. Record the distance marker when the cable changes direction and in between connectors.
Page 25: Calibrate Cable Resistance
A system configured using base resistance values will still be very accurate. If you wish to fine tune the resistance value of your LD5200 system to make it more precise, you may do so. This will increase the accuracy of the system, and bring the LD5200’s reported installed cable length value in line with the actual length of cable installed.
Page 26 380 feet 0 feet + 50 feet + 330 feet The actual resistance of the cable installed with this LD5200 is 2.881 ohms per foot. Replace the resistance per foot setting in the LD5200 with this newly calculated value. This can be edited on the Leak Configuration page of the web interface (Configuration >...
Page 27: Configure Security Settings
2.10 General Operation The LD5200 features both an LCD and a web interface. The LCD is accessible on the front of the device’s enclosure, and allows users to quickly access, acknowledge, and configure system settings, alarms, alarm history and device operations. The web interface provides more in-...
Page 28 Installation LD5200 User Guide 800.518.1519...
Page 29: Lcd Touch Screen Interface
HAPTER The LD5200’s LCD touch screen accommodates basic device configuration and operation. All the functionality you need to operate the LD5200 as a stand-alone device is accessible from the LCD touch screen. Virtual buttons line the right side of the screen, and they operate much like mechanical buttons.
Page 30: Main Menu
LCD Touch Screen Interface Main Menu When the LD5200 powers up, diagnostics are performed. The boot ROM and flash program code are verified. Once the diagnostics are complete, the LCD displays the Main Menu. Any time a screen within the LCD...
Page 31: Alarms Button
History View alarm history and Access the Alarm History screens. acknowledge all unacknowledged alarms Return Return to the Current Return to the Main Menu Alarms page. Table 3.4 LCD Current Alarm Buttons rletech.com LD5200 User Guide...
Page 32: History
Blue Acknowledged alarm Black Alarm condition has returned to normal, or additional information is provided regarding the LD5200’s functionality Table 3.5 LCD Alarm History Color Codes Use the Next, Previous, and Return buttons to navigate through the alarm history.Four buttons...
Page 33: Status Button
The field is also color coded to indicate the type of alarm. Cable Length The length of sensing cable connected to the controller, as calculated by the LD5200 Cable Current The amount of current running on the sensing cable Leg 1 Resistance The resistance of Leg 1 is displayed in Ohms.
Page 34 View the previous No additional options controller in the list of monitored devices System View additional system Network, EIA-485, Trend, Return information Return Return to the Current No additional options Alarms page. Table 3.8 LCD Controller Status Buttons LD5200 User Guide 800.518.1519...
Page 35: System Button
The log catalogs the data. last 365 entries. Previous: View the previous page of logged data. Return: Return to the System page for the selected controller. Return Return to the Status page. Table 3.9 LCD System Status Button Options rletech.com LD5200 User Guide...
Page 36: Setup Button
The blue highlight indicates which option is selected. Use the buttons on the right side of the LCD to navigate through the menus. Press the Select button to choose the blue highlighted option. LCD - Setup Menu LD5200 User Guide 800.518.1519...
Page 37: Leak Settings
LCD Touch Screen Interface 3.5.1 Leak Settings Leak Settings allows you to fine tune the leak detection options available on the LD5200. Use the Up, Down, Select and Return buttons to navigate through the leak settings menu. LCD - Leak Settings...
Page 38: Table 3.10 Lcd Leak Settings - Configurable Options
Default setting: 2.800 ohms per foot. Re-Alarm Delay The LD5200 can be set to re-alarm - after a leak or contamination has been detected, the alarm will be re-sent at a defined interval until the alarm condition has been resolved.
Page 39 Establish a 4-digit numerical password to restrict access to the Setup series of menus. Set the value to 0000 to disable password protection. Default setting: 0000 (no password) Table 3.10 LCD Leak Settings - Configurable Options rletech.com LD5200 User Guide...
Page 40: Virtual Zone
The LD5200 allows you to establish up to 32 virtual leak detection zones. Dividing a leak detection system into zones helps locate leaks quickly.
Page 41: Slave Zone
V-Zone Label the virtual zones. A device communicating via Modbus will have editable zone names and end distances. A device communicating via Bacnet will be read-only - the LD5200 will obtain the information from the other controller. Table 3.12 LCD Slave Zones Setup - Configurable Options rletech.com...
Page 42: 4-20Ma Output
5,000 feet of sensing cable. LCD - 4-20mA Output Settings Menu Option Description Leak Alarm Output Selectable: Span 5-19 mA (default) 4-20 mA Leak Alarm Output Selectable: Range 1000 (default) 2500 5000 Table 3.13 LCD 4-20mA Settings - Configurable Options LD5200 User Guide 800.518.1519...
Page 43: Preventative Maintenance
Default setting: 0000 (no password) Text Designate text to display when the maintenance reminder is triggered. Enter up to four lines of text (30 characters per line) Table 3.14 LCD Preventative Maintenance - Configurable Options rletech.com LD5200 User Guide...
Page 44: System Settings
Adjust the current time, in hh:mm:ss format, if necessary. IP Address Set the IP address for the LD5200, so it can communicate on your network. If you do not have an IP address for the device, obtain one from your IT department.
Page 45: Modbus / N2
LCD Touch Screen Interface 3.5.7 EIA-485 / Modbus / N2 If the LD5200 will be communicating via the EIA-485 port, configure the necessary options here. LCD - EIA485/Modbus/N2 Setup Menu Menu selections are as follows: Option Description TCP/UDP UID Set the TCP/UDP unique identifier. this will be a value between 1 and 254.
Page 46: Bacnet
Option Description Device Name Designate a unique name for the LD5200, up to 30 characters. Device ID Set the device ID, up to 30 characters. 0 = disabled. Description Enter a description for the device, up to 30 characters.
Page 47: Web Interface
HAPTER The LD5200’s LCD accommodates most device control and configuration. For more in-depth functionality, use the web interface. To access your LD5200’s web interface, type the device’s IP address into your web browser’s location bar. Home Page The LD5200’s home page features basic system information, including current alarm status, the reported length of sensing cable connected to the system, the last time the system went into alarm, and the running system uptime.
Page 48: Identity
LD5200 Web Interface Home Page with Active Leak Detected Alarm Identity The Identity link displays basic LD5200 information, including model number, system name, contact information, firmware version, and IP address. Most of these values can be adjusted through the Configuration screens. This page is intended for reference only, not system adjustment.
Page 49: Configuration
If any of the fields within the sub-menus are edited, be sure to click the Submit NOTE Changes button to save the changes. If you edit the fields and navigate from the web page without clicking the Submit Changes button, all changes will be lost. rletech.com LD5200 User Guide...
Page 50: Leak
Web Interface 4.3.1 Leak Use the Leak Configuration page to fine tune system variables, including leak and contamination thresholds, latching and unlatching alarms, and sensing cable resistance. Figure 4.5 Leak Configuration Page LD5200 User Guide 800.518.1519...
Page 51: Table 4.1 Leak Configuration Options
The amount of time that passes between the time a contamination Alarm Delay is detected and the annunciation of the contamination alarm. The contamination trip point must be exceeded for the duration of this delay. Default setting: 40 seconds Table 4.1 Leak Configuration Options rletech.com LD5200 User Guide...
Page 52 Default setting: 2.800 ohms per foot. Re-Alarm Interval The LD5200 can be set to re-alarm - after a leak or contamination has been detected, the alarm will be re-sent at a defined interval until the alarm condition has been resolved. The re-alarm triggers both the audible alarm and the direct notification alarm.
Page 53 If a loss of connectivity is being reported at your facility, you can disable the LCD reset. Use this option to enable or disable the 12:00 a.m. LCD reset. Default: Enabled Table 4.1 Leak Configuration Options (continued) rletech.com LD5200 User Guide...
Page 54 Push the button and then look at the web interface home page. If the controller is functioning properly, the cable length will register approximately 2878 feet, and the leg 1 and leg 2 resistance will be approximately 8060 ohms. LD5200 User Guide 800.518.1519...
Page 55: Virtual Zone
The LD5200 supports up to 32 virtual zones. Dividing a leak detection system into zones helps locate leaks quickly. It simplifies troubleshooting by allowing you to isolate different sections of cable as separately defined areas.
Page 56: Slave Controller
Web Interface 4.3.3 Slave Controller The LD5200 can act as a Modbus or Bacnet IP master for other RLE leak detection devices. Up to 127 slave devices can be connected to one LD5200. To configure the LD5200 as a Modbus master, refer to Chapter 5, “Modbus Communication” on page 87.
Page 57: Slave Zones
Slave Configuration menu. Label Type a descriptive label for the controller, 30 characters or less. End Distance For distance-read systems, the distance reading at the end of that virtual zone. Table 4.4 LDZ/Slave Zone Label Configuration Options rletech.com LD5200 User Guide...
Page 58: Network/Ip
The MAC address is a unique identifier set by the manufacturer, and is non-editable. IP Address Set the IP address for the LD5200, so it can communicate on your network. If you do not have an IP address for the device, obtain one from your IT department.
Page 59: Network Statistics
Web Interface 4.3.6 Network Statistics The Network Statistics link displays a snapshot of the most recent network information. Figure 4.11 Network Statistics Page rletech.com LD5200 User Guide...
Page 60: Web
Two separate passwords can be configured on the LD5200. Only The Read Only password allows users to access the LD5200’s web interface and view the conditions of the system, but does not allow users to make changes to the LD5200’s configuration.
Page 61: Map
Figure 4.13 Leak Detection Reference Map A .pdf or .vsd image can be uploaded to the LD5200, but .pdf and .vsd files do not support the interactive mapping overlays. Upload .pdf and .vsd files for visual reference only. Since the LD5200 never actually edits your map, if you should need to update your map image, previously designated map points will not need to be reconfigured.
Page 62: Figure 4.14 Map Settings Page
Web Interface The LD5200 allows users to upload 10 maps, and make all 10 of the maps interactive. Use the drop down menu on the upper right side of the Map Configuration screen (shown below) to upload and configure each individual map.
Page 63 Maps 2-10 - Link to preloaded image maps, which allows you to drill down into a graphical overview of the individual units. Slave Web Page - The LD5200 imports the links from the information entered on the Slave Controller Configuration page.
Page 64: Upload The Map Image
File size: less than 500kb Maximum physical size: 4000x4000 pixels Select the correct file and click the Upload button to load the file onto the LD5200. Table 4.7 Map Settings Options Several options on this page fall above the gray line that separates the image upload section of the page.
Page 65: Map Reference Points
Map Configuration Page Click the Upload button. The upload should take about seven seconds. Once the image of the map has uploaded, the LD5200 displays a message confirming that it has uploaded the new file. Figure 4.16 Map Image Upload Message If you receive the following error message, the file did not upload: Figure 4.17...
Page 66: Figure 4.18 Mapping Crosshairs - Reference Point
Throughout the mapping process, you will use a set of crosshairs to designate the location of your mapped points. The LD5200 firmware interprets the area directly in the center of the crosshairs as your reference point. Therefore, the point you’re mapping appears on the map wherever the center of the crosshairs is located when you click the mouse to designate the object’s location.
Page 67: Test The Mapped Coordinates
When you click on the map, the distance and x,y coordinates are stored by the LD5200 and associated with the distance you entered into the box at the top of the screen. Once the data has been saved, the map will reload, and the coordinate count at the top of the screen will increase by 1.
Page 68: Figure 4.24 Click The Map Alarm Test Link To View All Mapped Points In An Alarm State
Web Interface with their distance measurements. This demonstrates what the coordinates will look like when an alarm condition occurs. Figure 4.24 Click the Map Alarm Test Link to View All Mapped Points in an Alarm State LD5200 User Guide 800.518.1519...
Page 69 Edit the x, y, and distance values as necessary. To delete a coordinate, change all its values to 0. Click the Delete All Coordinates button to clear all the fields. Click the Submit Changes button to save all modifications. rletech.com LD5200 User Guide...
Page 70: Viewing The Map
Adjust the current date, in mm/dd/yy format, if necessary. Time Adjust the current time, in hh:mm:ss format, if necessary. A non-configurable field, the day of the week is generated based on the date. Table 4.8 Clock Configuration Options LD5200 User Guide 800.518.1519...
Page 71: Ntp
NTP, or Network Time Protocol, is used to synchronize clocks of computer systems. NTP synchronizes the time of a computer or device (the LD5200) with another computer or referenced time source. NTP maintains a high level or accuracy and reliability in time stamped events.
Page 72 Set the day DST begins at your location. Default setting: Second Sunday - March DST End Date Set the day DST ends at your location. Default setting: First Sunday - November Table 4.9 NTP Configuration Options LD5200 User Guide 800.518.1519...
Page 73: Email-Smtp/Dns
Default setting: LAN Options - The LD5200 will send alerts for leak and cable break alarms. Decide if you’d also like to receive email alerts for contamination alarms. If so, check this box. If false alarms are often detected on your system,...
Page 74 IT department. Default setting: Blank View Smtp Log / View a log of all email messages that have been sent by the LD5200. Send Test Email This link provides access to a button that generates and sends a test email.
Page 75: Snmp/Syslog
SNMP/Syslog Page Option Description System Name Designate a unique name for the LD5200, up to 30 characters. System Contact Enter up to four lines of text (30 characters per line) System Location Enter the address of the LD5200’s physical location.
Page 76 V3 - Inform (not available on standard unit) Default setting: V1 -Trap Max Inform Retries The number of times the LD5200 will attempt to resend an undelivered trap. Enter a number 0 - 999. Enter 0 for an unlimited number of attempts.
Page 77: Port/Modbus/N2
Web Interface 4.3.13 EIA-485 Port/Modbus/N2 If the LD5200 will communicate via the EIA-485 port, configure the necessary options here. Figure 4.30 Modbus EIA-485 Page Option Description Modbus/TCP/UDP This designator is used for Modbus RTU over an Ethernet Slave Unit Identifier connection.
Page 78 Set the slave address, 1-254. 0 = disabled Address Modbus Slave Click these links to display the corresponding data. Register Display Log Modbus Statistics Modbus Packet Log N2 Register Display Log / Statistics Table 4.12 Modbus/EIA-485 Options LD5200 User Guide 800.518.1519...
Page 79: Bacnet
Web Interface 4.3.14 Bacnet The LD5200 can communicate via BACnet. BACnet allows building automation and control devices to communicate, regardless of the services they perform. rletech.com LD5200 User Guide...
Page 80: Figure 4.31 Bacnet Page
Figure 4.31 Bacnet Page Option Description BACnet Device Designate a unique name for the LD5200, up to 30 characters Name BACnet Device ID Set the device ID, up to 30 characters. 0 = disabled BACnet Description Enter a description for the device, up to 30 characters Bacnet UDP Port Enter a 0 to specify port 47808 (0xBAC0) as the UDP port.
Page 81: Alarm Management
- that option is available on the Leak page. Reset Leak Alarm Resets the current leak alarm and causes the LD5200 to recheck the current cable conditions. This clears the alarm condition if the cable registers that the leak threshold is within an accepted range.
Page 82: System/Flash Management
Web Interface 4.3.16 System/Flash Management Use this page to update the LD5200’s firmware, the front panel LCD’s firmware, and to backup the LD5200’s configuration file. Refer to Appendix A, “Update Firmware” on page 103 for complete firmware update instructions. Figure 4.33...
Page 83: Historical Data
Web Interface Historical Data The Historical Data link provides access to logged historical data, including alarm and trending data.The LD5200’s historical data includes a time-stamped chronology of events and a trend log that contains occurrences of current leakage. Figure 4.34...
Page 84: Figure 4.35 Alarm History Text File (.Txt)
Table 4.17 Alarm History Log Description Alarm history data is also available as a text file (.txt.). Click the AlarmHistory.txt link to download the data as a text file. Figure 4.35 Alarm History Text File (.txt) LD5200 User Guide 800.518.1519...
Page 85: Refresh
Instead of waiting for the LD5200 to refresh on its own, click the link to force a system refresh.
Page 86 Web Interface LD5200 User Guide 800.518.1519...
Page 87: Modbus Communication
When using the leak detection master option, the LD5200 relays can be activated according to the slave unit alarm. If the slave has a leak alarm or a cable break alarm, the LD5200 leak or cable relay will change state, respectively (i.e. it will trigger that an alarm is present). The zone will then appear on the LCD and an alarm state will be reported to the top level of the system.
Page 88: Implementation Basics
5.3.1.2 Function Field The function field is one byte in length and tells the LD5200 which function to perform. The supported functions are 03 (Read 4xxxx output registers), 04 (Read 3xxxx input registers), 06 (Preset single register) and 16 (Preset multiple registers).
Page 89: Error Check (Checksum) Field
The LD5200 RTU mode uses a 16-bit cyclic redundancy check (CRC-16). Exception Responses If a Modbus master sends an invalid command to the LD5200 or attempts to read an invalid register, an exception response is generated. The response packet will have the high order bit of the function code set to one.
Page 90: Table 5.3 Output Registers
40012 Spare 0-65535 40013 Spare 0-65535 40014 Spare 0-65535 40015 Spare 0-65535 40016 Leak Alarm Delay Leak Alarm Delay 5-995 0-65535 seconds 40017 Contamination Alarm Contamination Alarm Delay 5-995 0-65535 Delay seconds Table 5.3 Output Registers LD5200 User Guide 800.518.1519...
Page 91: Function 04: Read Input Registers
Modbus Communication 5.4.2 Function 04: Read Input Registers To read the LD5200 input values, the master must send a Read Input Registers request packet. The Read Input Registers request packet specifies a start register and the number of registers to read. The start register is numbered from zero (30001 = zero, 30002 = one, etc).
Page 92: Table 5.5 Input Registers
Location of leak Ft/Meters 0-65535 30021 Modbus Zone6 Status Bit Level Status None 0-65535 30022 Modbus Zone6 Distance Location of leak Ft/Meters 0-65535 30023 Modbus Zone7 Status Bit Level Status None 0-65535 Table 5.5 Input Registers LD5200 User Guide 800.518.1519...
Page 93 Location of leak Ft/Meters 0-65535 30056 Modbus Zone23 Status Bit Level Status None 0-65535 30057 Modbus Zone23 Distance Location of leak Ft/Meters 0-65535 30058 Modbus Zone24 Status Bit Level Status None 0-65535 Table 5.5 Input Registers (continued) rletech.com LD5200 User Guide...
Page 94 Location of leak Ft/Meters 0-65535 30091 Modbus Zone40 Status Bit Level Status None 0-65535 30092 Modbus Zone40 Distance Location of leak Ft/Meters 0-65535 30093 Modbus Zone41 Status Bit Level Status None 0-65535 Table 5.5 Input Registers (continued) LD5200 User Guide 800.518.1519...
Page 95 Location of leak Ft/Meters 0-65535 30126 Modbus Zone57 Status Bit Level Status None 0-65535 30127 Modbus Zone57 Distance Location of leak Ft/Meters 0-65535 30128 Modbus Zone58 Status Bit Level Status None 0-65535 Table 5.5 Input Registers (continued) rletech.com LD5200 User Guide...
Page 96 Location of leak Ft/Meters 0-65535 30161 Modbus Zone74 Status Bit Level Status None 0-65535 30162 Modbus Zone74 Distance Location of leak Ft/Meters 0-65535 30163 Modbus Zone75 Status Bit Level Status None 0-65535 Table 5.5 Input Registers (continued) LD5200 User Guide 800.518.1519...
Page 97 Location of leak Ft/Meters 0-65535 30196 Modbus Zone91 Status Bit Level Status None 0-65535 30197 Modbus Zone91 Distance Location of leak Ft/Meters 0-65535 30198 Modbus Zone92 Status Bit Level Status None 0-65535 Table 5.5 Input Registers (continued) rletech.com LD5200 User Guide...
Page 98 Location of leak Ft/Meters 0-65535 30231 Modbus Zone108 Status Bit Level Status None 0-65535 30232 Modbus Zone108Distance Location of leak Ft/Meters 0-65535 30233 Modbus Zone109 Status Bit Level Status None 0-65535 Table 5.5 Input Registers (continued) LD5200 User Guide 800.518.1519...
Page 99 Location of leak Ft/Meters 0-65535 30266 Modbus Zone125 Status Bit Level Status None 0-65535 30267 Modbus Zone125 Distance Location of leak Ft/Meters 0-65535 30268 Modbus Zone126 Status Bit Level Status None 0-65535 Table 5.5 Input Registers (continued) rletech.com LD5200 User Guide...
Page 100: Table 5.6 Status Flags (Registers 30010 And 30011)
1 = Zone16 1 = Zone32 Table 5.6 Status Flags (Registers 30010 and 30011) Description 1= Leak Detected 1 = Cable Break 1 = Contamination 1 = Communication Loss Table 5.7 Status Flags (Register 30013 - 30273) LD5200 User Guide 800.518.1519...
Page 101: Function 06: Preset Single Register
Modbus Communication 5.4.3 Function 06: Preset Single Register To set the LD5200 parameter value, the master must send a Preset Single Register request packet. The Preset Single Register request packet specifies a register and the data to write to that register. The register is numbered from zero (40001 = zero, 40002 = one, etc).
Page 102: Rtu Framing
Modbus Communication RTU Framing The example below shows a typical Query/Response from the LD5200 module. Numbers Starting Starting Number of Slave Function Register Register Registers Registers CRC 16 Address Code “Msb” “Lsb” “Lsb” “Lsb” “Lsb” “Msb” Table 5.10 Query Sample...
Page 103: Update Firmware
(.bin file) for the LD5200. Using the same filename, save the file to a local drive and note the file’s location. IMPORTANT Do not change the name of the firmware file when you save it. The LD5200 will not recognize a renamed file.
Page 104: Figure A.2 Choose The Firmware File
During this process, the LD5200 module displays a “System is Rebooting.” message and then reboots. Figure A.3 Firmware Load Message Once the LD5200 has rebooted, the web interface returns to its Home page. The firmware update is complete, and the LD5200 has resumed its normal operation. LD5200 User Guide 800.518.1519...
Page 105: Beia-232 Interface
♦ The LD5200 erases a memory block and copies data to flash memory before rebooting. ♦ The LD5200 IP address is now set and the LD5200 can be accessed through a Web browser using the new IP address. rletech.com LD5200 User Guide...
Page 106: Boot Up
Make sure the EIA-232 port is connected to a PC or terminal with a straight through cable (not provided). Run terminal emulation software (i.e., HyperTerminal) and make sure the settings match the LD5200 EIA-232 port configuration; refer to “P1: EIA-232 Connector” on page 19 for port configuration details. When the LD5200 is powered up, diagnostics are performed.
Page 107: Other Main Menu Functions
Description netcfg Display the network configuration. login Log in to the system to make changes time Adjust the LD5200’s time. Enter the time in hh:mm:ss format. date Adjust the LD5200’s date. Enter the date in mm/dd/yy format. reset Reboot the unit back to the bootloader.
Page 108 EIA-232 Interface LD5200 User Guide 800.518.1519...
Page 109 Place water on the cable. Verify the Leak Detected alarm on the control panel. Compare the distance reading on the LD5200 LCD to the reference map to verify that the LD5200 displays the correct leak location. Dry the cable and verify that the LD5200 returns to normal.
Page 110: C Preventive Maintenance
Preventive Maintenance LD5200 User Guide 800.518.1519...
Page 111: Troubleshooting
AC power input terminal. If no AC power is present at the terminal block, check the input circuit breaker that powers the LD5200. If voltage is present, go to step 2. Check for 24 VDC at input power terminal block, TB7 pins 1 and 2.
Page 112: D Troubleshooting
5% of actual installed Length of Cable length. If your reading is not within 5%, verify that the LD5200 is operating with the correct cable resistance per foot for the sensing cable connected to the system. Consult “Leak Settings”...
Page 113 Power down (shut off) the control panel and remove the end-of- line terminator (EOL) from the end of the SC cable. Locate the first section of SC cable from the LD5200 control panel. Where it joins to the second section of cable, disconnect and install the End-of-Line terminator at the end of the first section of SC cable.
Page 114: Troubleshooting Sensing Cable
Use either a cable tester (RLE part # LDCE) or refer that it is ok without to the Cable Break Alarm assessment in Table D.1, “Troubleshoot sending it back to RLE Problems with the LD5200” to determine which section of cable for warranty may be faulty. evaluation? How do I secure RLE recommends the use of J-clips.
Page 115: Table D.2 Troubleshoot Sensing Cable
This requires replacement of the cable. The cable has become damaged - most often from a floor tile being dropped on it. Damaged cable must be repaired or replaced. Table D.2 Troubleshoot Sensing Cable (continued) rletech.com LD5200 User Guide...
Page 116 Troubleshooting LD5200 User Guide 800.518.1519...
Page 117: E 4-20Ma Output Testing
Place water on the end of the SC cable. Measure the DC voltage across the resistor. The value will be proportional to the length of cable measured by the LD5200 and scaled according to the range setting. Dry the cable.
Page 118 4-20mA Output Testing Turn off power to the LD5200. Remove the resistor and wires from the plug and reattach any wires as necessary. Reapply power to the LD5200. LD5200 User Guide 800.518.1519...
Page 119: F Technical Specifications
PECIFICATIONS HAPTER Table F.1 Technical Specifications Power Requires a dedicated circuit within close proximity, marked as the disconnecting device for the LD5200. 100-240VAC @ 500mA max, 50/60 Hz power supply; dedicated circuit required Inputs Sensing Cable Compatible with all SeaHawk sensing cables (not included) Cable Input Requires SeaHawk LC-KIT: 15ft (4.57m) leader cable and...
Page 120 12.5"W x 10"H x 3.25"D (318mmW x 254mmH x 83mmD) Weight 8.2 lbs. (3.7kg) Mounting Type 1 wall mount enclosure Certifications CE; ETL listed: conforms to UL 61010-1, EN 61010-1; certified to CSA C22.2 NO. 61010-1; RoHS compliant LD5200 User Guide 800.518.1519...

RLE Technologies LD5200 User Manual

1 Product Overview

2 Installation

3 LCD Touch Screen Interface

4 Web Interface

5 Modbus Communication

Update Firmware

BEIA-232 Interface

C Preventive Maintenance

100 C Preventive Maintenance

Troubleshooting

500 D Troubleshooting

E 4-20Ma Output Testing

F Technical Specifications

Quick Links

Troubleshooting

Need help?

Questions and answers

Related Manuals for RLE Technologies LD5200

Summary of Contents for RLE Technologies LD5200

Table of Contents
