F Technical Specifications
Table F.1 Technical Specifications (continued)
Protocols
EIA-485
EIA-232
RJ-45
Alarm Notification
Audible Alarm
Visible Alarm
Logging Capabilities
Alarm History/Event Log
Trend Log
Login Security
LCD Touch Screen
Web Interface
Front Panel Interface
Display
Operating Environment
Temperature
Humidity
Altitude
Storage Environment
Dimensions
Weight
Mounting
Certifications
120
Modbus RTU, Master & Slave; BACnet MS/TP; N2, Slave
Terminal emulation, VT100 compatible
Ethernet, TCP/IP; Modbus/TCP/UDP, Master & Slave;
SNMP V1, V2, V3, NTP, SMTP, DNS; BACnet/IP
85dBA @ 2ft (0.6m); re-sound 0-999min.
Alarm indicated on LCD touch screen and through web
interface
Logs are downloadable to .txt file
Last 1,024 events
Cable current level every day, for the last 365 days
No password required to view controller status and data.
Administrator password limits access to configuration
options.
Username and password can be configured.
480 x 272 pixel color backlit LCD touch screen;
95.04mm x 53.85 mm
32° to 122°F (0° to 50°C)
5% to 95% RH, non-condensing
15,000ft (4,572m) max.
-4° to 185°F (-20° to 85°C)
12.5"W x 10"H x 3.25"D
(318mmW x 254mmH x 83mmD)
8.2 lbs. (3.7kg)
Type 1 wall mount enclosure
CE; ETL listed: conforms to UL 61010-1, EN 61010-1;
certified to CSA C22.2 NO. 61010-1; RoHS compliant
