Configuring Video Connections; Video Data Sources - IONODES ION-R200 User Manual

ION-R200 – User manual

9.7 Configuring Video Connections

9.7.1 Video Data Sources

In the Configuration page, select the Video Out tab, then the Data Sources sub-tab. After
that, select the data source you want to configure. To configure an RTSP video connection, set
Data Source Type to Video over RTSP.
To connect to a video stream, the ION-R200 needs to know the Connection URI as well as any
Username and Password required by the camera or encoder. If you know the exact connection
URI of the video stream, you can type it in manually. Or you can use the discovery wizard by
clicking on Configure Data Source Using Discovery Wizard. The discovery wizard guides you
through a few simple steps in order to fill the data source configuration for you.
In the first step of the discovery wizard, set the type of data source to configure to Camera and
press Next.
Page 27 of 49
