7 Connections
The ION-R200 offers two separate digital video output connections as well as several USB and
audio connections.
7.1 Front Panel
1. 1 x USB 3.0
General purpose USB connector interface. This ports can be used to connect an
optional keyboard or mouse.
2. 1x USB 3.0 (with charging capability – Yellow)
General purpose USB connector interface with charging capabilities. Can be used to
recharge an external USB device.
3. AUDIO IN / OUT
3.5 mm jack which can be used to connect both an audio input and an audio output
source. The stereo channel provided by this connector exposes one channel for the
audio input and the other for the audio output.
Warning:
Audio support is currently not implemented on the ION-R200 and may be made availa-
ble in a future software update.
– User manual
ION-R200
Page 10 of 49
