Danfoss FC 101 Design Manual page 74

How to Programme
Parameter
1-24 Motor Current
1-25 Motor Nominal
Speed
1-26 Motor Cont. Rated
Torque
1-29 Automatic Motor
Adaption (AMA)
1-30 Stator Resistance
6 6
(Rs)
1-37 d-axis Inductance
(Ld)
1-39 Motor Poles
1-40 Back EMF at 1000
RPM
1-73 Flying Start
1-73 Flying Start
3-02 Minimum Reference -4999-4999
3-03 Maximum Reference -4999-4999
3-41 Ramp 1 Ramp Up
Time
3-42 Ramp 1 Ramp
Down Time
4-12 Motor Speed Low
Limit [Hz]
4-14 Motor Speed High
Limit [Hz]
4-19 Max Output
Frequency
5-40 Function Relay [0]
Function relay
5-40 Function Relay [1]
Function relay
6-10 Terminal 53 Low
Voltage
72
®
VLT HVAC Basic Drive FC 101 Design Guide
Range
0.01-10000.00 A
100.0-9999.0 RPM
0.1-1000.0
See 1-29 Automatic Motor
Adaption (AMA)
0.000-99.990
0-1000
2-100
10-9000
[0] Disabled
[1] Enabled
0.05-3600.0 s
0.05-3600.0 s
0.0-400 Hz
0.0-400 Hz
0-400
See 5-40 Function Relay
See 5-40 Function Relay
0-10 V
MG18C502 - Rev. 2013-09-06
Default Function
Size related Enter motor current from nameplate data
Size related Enter motor nominal speed from nameplate data
Size related This parameter is available only when 1-10 Motor
Construction Design is set to [1] PM, non-salient
SPM.
NOTICE
Changing this parameter affects
settings of other parameters
Off Performing an AMA optimises motor performance
Size related Set the stator resistance value
Size related Enter the value of the d-axis inductance.
Obtain the value from the permanent magnet
motor data sheet. The de-axis inductance cannot
be found by performing an AMA.
4 Enter the number of motor poles
Size related Line-Line RMS back EMF voltage at 1000 RPM
When PM is selected, Flying Start is enabled and
can not disable
0 Select [1] Enable to enable the frequency converter
to catch a motor spinning due to mains drop-out.
Select [0] Disable if this function is not required.
When is enabled 1-71 Start Delay and 1-72 Start
Function have no function. is active in VVC
mode only
0 The minimum reference is the lowest value
obtainable by summing all references
50 The maximum reference is the lowest obtainable
by summing all references
Size related Ramp up time from 0 to rated 1-23 Motor
Frequency if Asynchron motor is selected; ramp up
time from 0 to 1-25 Motor Nominal Speed if PM
motor is selected
Size related Ramp down time from rated 1-23 Motor Frequency
to 0 if Asynchron motor is selected; ramp down
time from 1-25 Motor Nominal Speed to 0 if PM
motor is selected
0 Hz Enter the minimum limit for low speed
65 Hz Enter the maximum limit for high speed
Size related Enter the maximum output frequency value
Alarm Select the function to control output relay 1
Drive running Select the function to control output relay 2
0.07 V Enter the voltage that corresponds to the low
reference value
