Decoupling Plate; Mg18C502 - Rev. 2013-09-06 - Danfoss FC 101 Design Manual

Selection
Frame IP class
3 x 200-240 V
H1 IP20 0.25-1.5 kW
H2 IP20 2.2 kW
H3 IP20 3.7 kW
H4 IP20 5.5-7,5 kW
H5 IP20 11 kW
H6 IP20 15-18.5 kW
H7 IP20 22-30 kW
H8 IP20 37-45 kW
H9 IP20
H10 IP20
Table 3.3 Enclosure Kit Specifications

3.1.4 Decoupling Plate

Use the decoupling plate for EMC correct installation.
Shown here on a H3 enclosure.
99
Illustration 3.7 Decoupling Plate
Frame IP class
H1 IP20
H2 IP20
H3 IP20
H4 IP20
H5 IP20
H6 IP20
H6 IP20
H7 IP20
H7 IP20
H8 IP20
Table 3.4 Decoupling Plate Specifications
NOTICE
For H9 and H10 frequency converters, the decoupling plates are included in the accessory bag.
®
VLT HVAC Basic Drive FC 101 Design Guide
Power
3 x 380-480 V 3 x 525-600 V
0.37-1.5 kW
2.2-4 kW
5.5-7.5 kW
11-15 kW
18.5-22 kW
30-45 kW 18.5-30 kW
55-75 kW 37-55 kW
90 kW 75-90 kW
2.2-7.5 kW
11-15 kW
99
3 x 200-240 V 3 x 380-480 V
0.25-1.5
2.2
3.7
5.5-7.5
11
15-18.5
22-30
37-45

MG18C502 - Rev. 2013-09-06

Height Width Depth [mm]
[mm] A [mm] B
293 81
322 96
346 106
374 141
418 161
663 260
807 329
943 390
372 130
475 165
Power [kW]
3 x 525-600 V
0.37-1.5
2.2-4
5.5-7.5
11-15
18.5-22
30 18.5-30
37-45
55 37-55
75
90 75-90
IP21 kit Type 1 kit
C ordering ordering no.
no.
173 132B0212 132B0222
195 132B0213 132B0223
210 132B0214 132B0224
245 132B0215 132B0225
260 132B0216 132B0226
242 132B0217 132B0217
335 132B0218 132B0218
335 132B0219 132B0219
205 132B0220 132B0220
249 132B0221 132B0221
Decoupling plate
132B0202
132B0202
132B0204
132B0205
130B0205
132B0207
132B0242
132B0208
132B0243
132B0209
3 3
43
