How to Install
1
2
3
Illustration 5.12 I2 Frame
IP54 380-480 V 0.75-4.0 kW
1 RS-485
2 Line in
3 Earth
4 Wire clamps
5 Motor
6 UDC
7 Relays
8 I/O
Table 5.12 Legend to Illustration 5.12
®
VLT HVAC Basic Drive FC 101 Design Guide
8
7
6
5
4
Illustration 5.13 I3 Frame
IP54 380-480 V 5.5-7.5 kW
1 RS-485
2 Line in
3 Earth
4 Wire clamps
5 Motor
6 UDC
7 Relays
8 I/O
Table 5.13 Legend to Illustration 5.13
MG18C502 - Rev. 2013-09-06
5 5
