How to Install
Power [kW]
3x380-480 V IP54
0.75
1.5
2.2
3
4
5.5
5 5
7.5
11
15
18.5
22
30
37
45
55
75
90
Table 5.17 Circuit Breakers and Fuses
64
®
VLT HVAC Basic Drive FC 101 Design Guide
Circuit Breaker
UL Non UL
PKZM0-16
PKZM0-16
PKZM0-16
PKZM0-16
PKZM0-16
PKZM0-25
PKZM0-25
PKZM4-63
PKZM4-63
PKZM4-63
Moeller NZMB1-A125
Moeller NZMB2-A160
Moeller NZMB2-A250
Bussmann Bussmann
Type RK5 Type RK1
FRS-R-10 KTS-R-10
FRS-R-10 KTS-R-10
FRS-R-15 KTS-R-15
FRS-R-15 KTS-R-15
FRS-R-15 KTS-R-15
FRS-R-25 KTS-R-25
FRS-R-25 KTS-R-25
FRS-R-50 KTS-R-50
FRS-R-50 KTS-R-50
FRS-R-80 KTS-R-80
FRS-R-80 KTS-R-80
FRS-R-125 KTS-R-125
FRS-R-125 KTS-R-125
FRS-R-125 KTS-R-125
FRS-R-200 KTS-R-200
FRS-R-200 KTS-R-200
FRS-R-250 KTS-R-250
MG18C502 - Rev. 2013-09-06
Fuse
UL
Bussmann Bussmann
Type J Type T
JKS-10 JJS-10
JKS-10 JJS-10
JKS-15 JJS-15
JKS-15 JJS-15
JKS-15 JJS-15
JKS-25 JJS-25
JKS-25 JJS-25
JKS-50 JJS-50
JKS-50 JJS-50
JKS-80 JJS-80
JKS-80 JJS-80
JKS-125 JJS-125
JKS-125 JJS-125
JKS-125 JJS-125
JKS-200 JJS-200
JKS-200 JJS-200
JKS-200 JJS-200
Non UL
Max fuse
Type G
16
16
16
16
16
25
25
63
63
63
125
125
125
160
160
200
200
