Selection
Step 4
Connect cable to frequency converter.
3 3
Illustration 3.4 Connect Cable
NOTICE
Use the provided thread cutting screws to fasten
connector to the frequency converter, tightening torque
1.3 Nm.
42
®
VLT HVAC Basic Drive FC 101 Design Guide

3.1.3 IP21/TYPE 1 Enclosure Kit

IP21/TYPE 1 is an optional enclosure element available for
IP20 units.
If the enclosure kit is used, an IP20 unit is upgraded to
comply with enclosure IP21/TYPE 1.
Illustration 3.5 H1-H5
Illustration 3.6 Dimensions
MG18C502 - Rev. 2013-09-06
B
C
On
Warn.
Alarm
