How to Order
4.2.2 Harmonic Filters
3x380-480 V 50 Hz
Power Drive input Default
[kW] current switching
Continuous frequency
[A] [kHz]
22 41.5 4
30 57 4
37 70 4
45 84 3
55 103 3
75 140 3
90 176 3
Table 4.3 AHF Filters (5% current distortion)
3x380-480 V 50 Hz
Power Drive input Default
[kW] current switching
Continuous frequency
[A] [kHz]
22 41.5 4
30 57 4
37 70 4
45 84 3
55 103 3
75 140 3
90 176 3
Table 4.4 AHF Filters (10% current distortion)
®
VLT HVAC Basic Drive FC 101 Design Guide
THID Order Code
level number number
[%] filter IP00 filter IP20
4 130B1397 130B1239
3 130B1398 130B1240
3 130B1442 130B1247
3 130B1442 130B1247
5 130B1444 130B1249
4 130B1445 130B1250
4 130B1445 130B1250
THID Order Code
level number number
[%] filter IP00 filter IP20
6 130B1274 130B1111
6 130B1275 130B1176
9 130B1291 130B1201
9 130B1291 130B1201
9 130B1292 130B1204
8 130B1294 130B1213
8 130B1294 130B1213
MG18C502 - Rev. 2013-09-06
3x440-480 V 60 Hz
Power Drive input Default
[kW] current switching
Continuous frequency
[A] [kHz]
22 34.6 4
30 49 4
37 61 4
45 73 3
55 89 3
75 121 3
90 143 3
Table 4.5 AHF Filters (5% current distortion)
3x440-480 V 60 Hz
Power Drive input Default
[kW] current switching
Continuous frequency
[A] [kHz]
22 34.6 4
30 49 4
37 61 4
45 73 3
55 89 3
75 121 3
90 143 3
Table 4.6 AHF Filters (10% current distortion)
THID Order Code
level number number
[%] filter IP00 filter IP20
3 130B1792 130B1757
3 130B1793 130B1758
3 130B1794 130B1759
4 130B1795 130B1760
4 130B1796 130B1761
5 130B1797 130B1762
5 130B1798 130B1763
THID Order Code
level number number
[%] filter IP00 filter IP20
6 130B1775 130B1487
8 130B1776 130B1488
7 130B1777 130B1491
9 130B1778 130B1492
8 130B1779 130B1493
9 130B1780 130B1494
10 130B1781 130B1495
