2 Specifications

2.1 Core System

CPU: 4th Generation Intel® Core™ and Celeron® Processors - 22nm, (formerly known as "Haswell Platform")
Intel® Core™ i7-4860EQ 2.4 GHz (3.2 GHz Turbo), 47W (4C/GT3)
Intel® Core™ i7-4700EQ 2.4/1.7 GHz (3.4 GHz Turbo), 47/37W (4C/GT2)
Intel® Core™ i5-4400E 2.7 GHz (3.3 GHz Turbo), 37W (2C/GT2)
Intel® Core™ i5-4402E 1.6 GHz (2.7 GHz Turbo), 25W (2C/GT2)
Intel® Core™ i3-4100E 2.4 GHz (no Turbo) 3MB, 37W (2C/GT2)
Intel® Core™ i5-4102E 1.6 GHz (no Turbo) 3MB, 25W (2C/GT2)
Intel® Celeron 2000E 2.2 GHz (no Turbo) 35W (2C/GT1)
Intel® Celeron 2002E 1.5 GHz (no Turbo) 25W (2C/GT1)
L3 Cache: 6MB for i7-4650U, 3MB for i5-4400E, i5-4402E, i3-4100E and i3-4102E, 2MB for 2000E and 2002E
Memory:
Dual channel ECC 1600/1333 MHz DDR3L memory up to 16GB in dual SODIMM socket
Chipset: Mobile Intel®
QM87
Mobile Intel®
HM86
BIOS:
AMI EFI with CMOS backup in 8MB SPI BIOS with Intel® AMT 9.0 support (Intel® AMT not supported by HM86)

2.2 Expansion Busses

PCI Express x16 (Gen3) or PCI Express (2 x8 or 1 x8 with 2 x4)
6 PCI Express x1 (AB): Lanes 0/1/2/3/4/5
1 PCI Express x1 (CD): Lane 6
LPC bus, SMBus (system) , I

2.3 Video

Integrated in Processor: Intel® Generation 7.5 graphics core architecture
GPU Feature Support:
3 independent and simultaneous display combinations of DisplayPort / HDMI / LVDS monitors
Encode/transcode HD content
Playback of high definition content including Blu-ray Disc*
Superior image quality with sharper, more colorful images
Playback of Blu-ray* disc S3D content using HDMI (1.4a spec compliant with 3D)
DirectX* Video Acceleration (DXVA) support for accelerating video processing
Full AVC/VC1/MPEG2 HW Decode
Advanced Scheduler 2.0, 1.0, XPDM support
Windows* 8, Windows* 7, OSX, Linux* OS support
DirectX 11, DirectX
Multi Display Support: 3 independent displays
Display Types
VGA Interface support with 300 MHz DAC Analog monitor support up to QXGA (2048 x 1536)
LVDS Interface single/dual channel 18/24-bit LVDS through eDP (two lane) to LVDS Realtek RTD2136R
Digital Display Ports x3
DDI1 supporting DisplayPort / HDMI / DVI
DDI2 supporting DisplayPort / HDMI / DVI
DDI3 supporting DisplayPort / HDMI / DVI
Express-HLE
Chipset (Intel® Core™ i7/i5/i3)
Chipset (Intel® Celeron)
C (user)
2
Page 7
