2.10

Power Specifications

Power Modes:
AT and ATX mode (AT mode start controlled by SEMA)
Standard Voltage Input: ATX = 12V±5% / 5Vsb ±5% or AT = 12V ±5%
Wide Voltage Input:
ATX = 8.5~20 V / 5Vsb ±5% or AT = 8.5 ~20V
Power Management: ACPI 4.0 compliant, Smart Battery support
Power States: supports C1-C6, S0, S1, S4, S3, S5, S5 ECO mode (Wake on USB S3/S4, WOL S3/S4/S5)
2.11

Operating Temperatures

Standard Operating Temperature: 0°C to 60°C (wide voltage input)
Extreme Rugged Operating Temperature: -40°C to 85°C (standard voltage input)
2.12

Environmental

Humidity: 5-90% RH operating, non-condensing
5-95% RH storage (and operating with conformal coating).
Shock and Vibration: IEC 60068-2-64 and IEC-60068-2-27
MIL-STD-202F, Method 213B, Table 213-I, Condition A and Method 214A, Table 214-I, Condition D
Halt:
Thermal Stress, Vibration Stress, Thermal Shock and Combined Test
2.13

Specification Compliance

PICMG COM.0: Rev 2.1 Type 6, basic size 125 x 95
2.14

Operating Systems

Standard Support:
Extended Support (BSP): WEC7/8, Linux , VxWorks
Express-HLE
Windows 7/8 32/64-bit, Linux 32/64-bit
Page 9
