APIC Mode (cont'd)
IRQ# Typical Intterupt Resource
16 N/A
17 N/A
18 N/A
19 N/A
20 N/A
21 N/A
22 N/A
23 N/A
Note (1): These IRQs can be used for PCI devices when onboard device is disabled.
Express-HLE
Connected to Pin
Intel HDA, PCIE Port 0/1/2/3/4/5/6, EHCI Conterller
#2 ,P.E.G Root Port, I.G.D ,XHCI Controller
PCIE Port 0/1/2/3/4/5/6, P.E.G Root Port,
PCIE Port 0/1/2/3/4/5/6, P.E.G Root Port, SMBus
Controller, EHCI Controller #2
PCIE Port 0/1/2/3/4/5/6, P.E.G Root Port,
Gbe Controller
Intel HDA
EHCI Controller #1
Available
Note (1)
Note (1)
Note (1)
Note (1)
Note (1)
Note (1)
Note (1)
Note (1)
