- Page 1 ® NuIPC cPCI-8210/8211/8212 3U CompactPCI Ethernet & SCSI Controller User’s Guide Recycled Paper...
- Page 3 Acknowledgments NuIPC and cPCI-8210/8211/8212 are registered trademarks of ADLINK Technology Inc. All trademarks and registered trademarks mentioned herein are the property of their respective owners.
- Page 4 Getting service from ADLINK ♦ Customer Satisfaction is always the most important thing for ADLINK Tech Inc. If you need any help or service, please contact us and get it. ADLINK Technology Inc. Web Site http://www.adlink.com.tw Sales & Service service@adlink.com.tw NuDAQ nudaq@adlink.com.tw...
-
Page 5: How To Use This Guide
How to use this guide This manual is to help you use cPCI-8210/8211 series modules. It describes how to install and arrange various settings. The briefs are as following: • Chapter 1, “Introduction” gives an overview of the product’s pecifications. It also tells you what are included in the product package. -
Page 7: Table Of Contents
2.5.3 cPCI-8211 Layout..............18 2.5.4 cPCI-8212 Layout..............19 Jumper & Switches Setting ..........20 2.6.1 cPCI-8210 Switched Setting ..........20 2.6.2 cPCI-8211/8211R Jumper Setting ........20 2.6.3 cPCI-8212R Jumper Setting..........21 Pin-definition of 68-pin Wide Ultra2 SCSI Connector..22 Pin-definition of 50-pin Ultra SCSI Connector....23 Pin-definition of RJ45 Connector ........ -
Page 9: Chapter 1 Introduction
Introduction The cPCI-8210 Series products are the high performance Ethernet / SCSI controllers which comply with the CompactPCI standards. Two major functions are supported: • 10 Base-T / 100 Base-TX Fast Ethernet and • Wide Ultra-2 SCSI interface The cPCI-8211 integrates the high performance Ethernet controller , and the cPCI-8211R supports the rear connection ,which cooperates with the R8211 daughter board. - Page 10 the higher rate, as well as much longer SCSI cable tolerance up to 12 meters. The 53C895 is backward compatible with all the SCSI standards. It could automatically detect the devices connected to the subsystem. If the devices are also Wide Ultra-2 SCSI compliant, the 53C895 runs in the highest mode that the LVD link is enabled, otherwise the 53C895 will fall back to the older mode automatically.
-
Page 11: What Is Fast Ethernet
The date comes from STA (SCSI Trade Association) The cPCI-8211 & cPCI-8211R use the Intel 82559 single chip Ethernet controller. The 82559 chip integrates the MAC (Media Access Controller) chip and the PHY chip (Physical layer interface). The 82559 is a sophisticated PCI bus master with enhanced scatter-gather bus -mastering capability that could detect the speed and the duplex automatically. -
Page 12: Specifications
♦ System architecture: • Standard 3U CompactPCI form factor • Advanced 10 Base-T/ 100 Base-TX Ethernet • Fully complied with PICMG 2.0 (CompactPCI) Rev2.0 ♦ cPCI-8210 Features: Ethernet I/F • Intel 82558 Ethernet Controller • Complied with PCI V2.1, IEEE802.3, IEEE802.3u •... - Page 13 • True 32-bit cPCI bus master • Full duplex support • 100Mbps Fast Ethernet or 10Mbps data transfer, selected via auto- negotiation • Suppose INTEL PREBOOT EXECUTION ENVIRONMENT (PXE) for remote boot (82559 Only) • 10 Base-T/ 100 Base-TX support •...
- Page 14 • cPCI-8210: 5V @ 2A (max.) • cPCI-8211& cPCI-8211R: 5V @ 100 mA (max) • cPCI-8212 & cPCI-8212R: 5V @ 1A (max) ♦ Environment • Operating Temperature: 0 to 60 • Storage Temperature: -20 to 80 • Humidity: 10%~90% non condensing...
-
Page 15: Chapter 2 Installation & Configurations
Installation & Configurations What you have ♦ cPCI-8210 3U Compact PCI board x 1 ADLINK CD-ROM This manual ♦ cPCI-8211 3U Compact PCI board x 1 R8211 daughter board x1 (only for cPCI-8211R) ADLINK CD-ROM This manual ♦ cPCI-8212 3U Compact PCI board x 1... -
Page 16: Connect The Network Cable
Connect the Network Cable Category 5 UTP cable qualifies for both, the Fast Ethernet And Ethernet, cabling rules. The maximum length of any single cable run between any station and its supporting Hub is 100 meter .The maximum length of a cable joining two hubs is 10m in general, but is 100m when both hubs qualify as Ethernet class 2 Repearters. -
Page 17: Device Installation For Windows 98
Device Installation for Windows 98 cPCI-8211/8211R & cPCI-8210 (LAN) While you first plug cPCI-8210 card and enter Windows 98, the system will detect this device automatically, and auto setup its driver. The cPCI-8211 must “Add New Hardware Wizard” to setup its device. When the user want to update device driver, user can choose the “... - Page 18 Express PRO Adapter ”. cPCI-8212/8212R & cPCI-8210 (SCSI) While you first plug cPCI-8212 or cPCI-8210 card and enter Windows 98, the system will detect this device automatically, and auto setup its driver. When the user want to update device driver, user can choose the “ Update Driver”, and show the following dialog box that prompts you to select the...
- Page 19 “Symbios 8951U 8952U PCI SCSI Adapter 53C895 Driver”(X indicates the CDROM driver)and then click OK. The system will start the installation cPCI-8212. install cPCI-8210 Type X:\NUIPC\8210\SCSI\WIN95 in the input field. Installation & Configuration • 11...
-
Page 20: Device Installation For Windowsnt
“Intel(R)”(X indicates the CD ROM driver) and then click OK. The system will start the installation of cPCI- 8211. If install cPCI-8210 Type “X:\NUIPC\8210\LAN in the input field and choose the model “Intel Ether Express PRO Adapter”. - Page 21 Use cPCI-8212/8212R&cPCI-8210(SCSI)driver to setup Windows NT4.0 Step1: Copy ADLINK’s “Manual & Software Utility CD”X:\NUIPC\8212\WINNT\WINNTHI\I386\WIN Nt all files to floppy disk. Step2: Use Windows NT boot disk to boot your computer. Step3: When install Windows NT disk 2 to setup Windows NT system.
- Page 22 Add cPCI-8212/8212R & cPCI-8210 (SCSI) driver to Windows NT4.0 While you first plug cPCI-8211 card and enter Windows NT. Step1: Select Control Panel. Step2: Select SCSI Adapter. Step3: Select Drivers then select Add. Step4: Place ADLINK’s “Manual & Software Utility ”CD into the appropriate driver.
- Page 23 Installation & Configuration • 15...
-
Page 24: Pcb Panel & Layout
PCB Panel & Layout 2.5.1 cPCI-8211 Panel cPCI-8211 cPCI-8211R R8211 LINK LINK 100M 100M Front LED-definition of LED 1,2,3 ACT: LAN active LINK: LAN Link 100M: 10/100 Mbps CN1: RJ45 Connector Figure 2.5.1 Panel of cPCI-8211/8211R 16 • Installation & Configuration... -
Page 25: Cpci-8212/8210 Panel
Transmission mode (Low Voltage Differential & Single– Ended) ACT(SCSI): SCSI active LINK: LAN Link 100M: 10/100 Mbps ACT(LAN): LAN active CN1: 68-pin Wide Ultra-2 SCSI Connector CN2: RJ45 Connector Figure 2.5.2 Panel of cPCI-8212 / cPCI-8210 Installation & Configuration • 17... -
Page 26: Cpci-8211 Layout
2.5.3 cPCI-8211 Layout 18 • Installation & Configuration... -
Page 27: Cpci-8212 Layout
2.5.4 cPCI-8212 Layout Installation & Configuration • 19... -
Page 28: Jumper & Switches Setting
Jumper & Switches Setting 2.6.1 cPCI-8210 Switched Setting Switches on the I/O card are used to select options for different components used. The switch-on /off is to accommodate the variations of the flash Boot ROM. The flash ROM is optional. When the flash ROM is... -
Page 29: Cpci-8212R Jumper Setting
2.6.3 cPCI-8212R Jumper Setting The cPCI-8212R supposes front and rear connection. When the front and rear are both connected device, like fig 2.6.1,the terminate of the cPCI- 8212R should be disabled. cPCI-8212R R-8212 Device Device Figure 2.6.1 JP1: Terminate enable & disable setting Enable terminate Disable terminate (Default Setting) -
Page 30: Pin-Definition Of 68-Pin Wide Ultra2 Scsi Connector
Pin-definition of 68-pin Wide Ultra2 SCSI Connector 68-pin Wide Ultra2 SCSI Connector The table below shows the pin-out assignments of this 68-pin connector. Signal Name Pin # Pin # Signal Name LVDP12 LVDM12 LVDP13 LVDM13 LVDP14 LVDM14 LVDP15 LVDM15 LVDPHP LVDPHM LVDP0 LVDM0... -
Page 31: Pin-Definition Of 50-Pin Ultra Scsi Connector
Pin-definition of 50-pin Ultra SCSI Connector 50-pin Ultra SCSI Connector The table below shows the pin-out assignments of this 50-pin connector. Signal Name Pin # Pin # Signal Name LVDP0 LVDM0 LVDP1 LVDM1 LVDP2 LVDM2 LVDP3 LVDM3 LVDP4 LVDM4 LVDP5 LVDM5 LVDP6 LVDM6... -
Page 32: Pin-Definition Of Rj45 Connector
Pin-definition of RJ45 Connector RJ45 Connector This connector is for the 10/100Mbps Ethernet capability of the CPU card. The figure below shows the pin out assignments of this connector and its corresponding input jack. Pin#1: TD+ Pin#5: NC Pin#2: TD- Pin#6: RD- Pin#3: RD+ Pin#7: NC Pin#4: NC... -
Page 33: Product Warranty/Service
Product Warranty/Service ADLINK warrants that equipment furnished will be free from defects in material and workmanship for a period of one year from the date of shipment. During the warranty period, we shall, at our option, either repair or replace any product that proves to be defective under normal operation. This warranty shall not apply to equipment that has been previously repaired or altered outside our plant in any way as to, in the judgment of the manufacturer, affect its reliability.
