Function Diagram - ADLINK Technology COM Express Express-HLE User Manual

2.15

Function Diagram

1333/1600 MHz
1~8 GB DDR3L
1333/1600 MHz
1~8 GB DDR3L
single / dual
18/24-bit LVDS RTD2136R
VGA
6x PCIe x1 (Gen2)
(port 0~5)
i217LM
4x SATA3 (QM87)
2x SATA3 & 2x SATA2 (HM86)
8x USB 1.1/2.0
HD Audio
UART0
UART1
NCT5104D
Debug
header
LPC bus
4x GP0
4x GPI
PCA9535
SMBus
2
GP I C
2
DDC I C
Page 10
eDP
2 lane
"Haswell"
PCIe x1
(port 7)
Mobile Intel®
QM87/HM86
Chipset
ATMEL
AT97SC3204
SPI_CS#
SPI
60-pin
DDI 2 (port C)
DP / HDMI / DVI
DDI 3 (port D)
DP / HDMI / DVI
PCI Express x16 (Gen3)
2 x8 or 1 x8 + 2 x4
4x USB 3.0 upgrade (QM87)
2x USB 3.0 upgrade (HM86)
1x PCIe x1 (Gen2)
(port 6)
SPI_CS0
SPI_CS1
-40+85°C
Express-HLE
