2.4 Audio

Integrated: Intel® HD Audio integrated in PCH QM87/QM86
Audio Codec: Realtek ALC886 on Express-BASE6

2.5 LAN

Integrated: LAN MAC integrated in PCH QM87/HM86
Intel PHY: Intel® Ethernet Controller i217LM
Interface: 10/100/1000 GbE connection

2.6 Multi I/O and Storage

Integrated in Intel® QM87/HM86 Chipset
USB ports:
4 ports USB 3.0 (USB0,1 ,2 ,3) and 4 ports USB 2.0 (USB4, 5, 6, 7) – QM87
2 ports USB 3.0 (USB0, 1) and 6 ports USB 2.0 (USB3, 4, 5, 6, 7) – HM86
SATA ports: 4 ports SATA 6Gb/s (SATA0, 1, 2, 3) – QM87
2 ports SATA 6Gb/s (SATA0, 1) and 2 ports SATA 3Gb/s (SATA2, 3) – HM86
Serial: 2 UART ports COM1/2 with console redirection
GPIO: 4 GPO and 4 GPI with interrupt

2.7 TPM (Trusted Platform Module)

Chipset: ATMEL
AT97SC3204
Type: TPM 1.2

2.8 SEMA Board Controller

Type: ADLINK Smart Embedded Management Agent (SEMA)
Supports:
Voltage/Current monitoring
Power sequence debug support
AT/ATX mode control
Logistics and Forensic information
Flat Panel Control
General Purpose I2C
Failsafe BIOS (dual BIOS )
Watchdog Timer and Fan Control

2.9 Debug

40-pin flat cable connector to be used with DB-40 debug module
supports: BIOS POSTCODE LED, BMC access, SPI BIOS flashing, Power Testpoints, Debug LEDs
60-pin XDP header for ICE debug of CPU/Chipset
Page 8
