7.3.5.1 USB > PCH USB Configuration
Feature
USB Precondition
XHCI Mode
BTCG
USB Precondition
USB Port #0~13
USB30 Port #0~5
7.3.6 Network
Feature
Network Stack
Network Stack
PCH LAN Controller
Wake on LAN
AMT Configuration
Intel AMT
BIOS Hotkey Pressed
MEBx Selection Screen
Hide Un-Configure ME Confirmation
MEBx Debug Message Output
Un-Configure ME
Amt Wait Timer
Disable ME
ASF
Activate Remote Assistance Process
USB Configure
Page 62
Options
Disabled
Enabled
Disabled
Enabled
Disabled
Enable
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Options Description
Info only
Enabled Enable/Disable UEFI network stack.
Disabled
Enabled Enable/Disable onboard NIC.
Disabled
Enabled Enable/Disable integrated LAN to wake the system. (The Wake On
Disabled LAN cannot be disabled if ME is on at Sx state.
Info only
Enabled Enable/Disable Intel (R) Active Management Technology BIOS
Disabled Extension.
Enabled Enable/Disable BIOS hotkey press.
Disabled
Enabled Enable/Disable MEBx selection screen.
Disabled
Enabled Hide Un-Configure ME without password Confirmation Prompt.
Disabled
Enabled Enable MEBx debug message output.
Disabled
Enabled Un-Configure ME without password.
Disabled
0 Set timer to wait before sending ASF_GET_BOOT_OPTIONS.
Enabled Set ME to Soft Temporary Disabled.
Disabled
Enabled Enable/Disable Alert Specification Format.
Disabled
Enabled Trigger CIRA boot.
Disabled
Enabled Enable/Disable USB Configure function.
Disabled
Description
Precondition work on USB host controller and root ports for
faster enumeration.
Mode of operation of xHCI controller.
Enable/Disable trunk clock gating.
Precondition work on USB host controller and root ports for
faster enumeration.
Control each of the USB ports (0~13) disabling.
Enable or Disable USB 3.0 Port.
Express-HLE
