1.1.1. INSTALLING BATTERY

For shipping and storage purposes, the mobile computer and the main battery are saved in
separate packages.
Note: Any improper handling may reduce the battery life.
To install the main battery:
1) Push the battery lock at the top of the battery cover to the right in order to unlock.
2) The battery cover will open automatically.
3) Insert the main battery with the contact pins facing the lower end. Fix the top edge of
the battery first.
4) Press down the lower edge of the battery.
5) Fix the lower edge of the battery cover, then push the upper end in.
6) Push the battery lock to the left to lock.
Warning:
(1) Check that the battery lock is at the "lock" position before powering on the device.
(2) For initial use, insert a charged battery, lock the battery cover in place, then press
the Power key to power on the mobile computer.
Chapter 1 Quick Start
7
