CipherLab RS30 Reference Manual page 20

RS30 Mobile Computer
No. Description
1 Proximity+ALS Sensor Hole
3 Status LED
5 Power Button
7 Side Key
9 Wristband Slot
11 Headset Jack
13 Camera Flash
15 Battery Cover Latch
17 NFC Detection Area
19 Side Key
6
No. Description
2 Receiver
4 Touchscreen
6 Micro USB Port
8 Speaker
10 Charging Pins
12 Scan Window
14 Camera
16 Battery Cover
18 Volume Buttons
20 Wristband Slot
Reference Manual
