2D IMAGER (SE4500DL)
The tables below list the symbology settings for 2D imager (SE4500DL).

SYMBOLOGY SETTINGS

1D SYMBOLOGIES
Symbology
CODABAR
CodaBar
Codabar
Length option
CLSI Editing
NOTIS Editing
NOTIS Editing Type
Verify Check Digit
Transmit Check Digit
CODE 11
Code 11
Code 11
Description
Switch to enable Codabar decoding.
Sets the length of the Codabar symbols to decode.
One Fixed length (Length 1)
Two Fixed lengths (Length 1>Length 2)
Max / Min Length (range: 0-55; Length 1<Length 2)
Any Length
When applied, the CLSI editing strips the start/stop
characters and inserts a space after the first, fifth, and tenth
characters of a 14-character Codabar barcode.
The 14-character barcode length does not include start/stop
characters.
Sets whether to include start/stop characters in the
transmitted data.
NOTIS Editing is to strip the start/stop characters, i.e. to disable
"Transmit Start/Stop Characters".
Options are None, ABCD/ABCD, abcd/abcd.
"NOTIS Editing" must be enabled.
Selects whether to verify the Modulo 43 check digit. If the
check digit is incorrect, the barcode will not be accepted.
Decide whether to include the check digit in the data to
transmit.
"Verify Check Digit" must be enabled.
Switch to enable Code 11 decoding.
Appendix IV
Default
Enable
Enable
Max / Min
Length
(4-55)
Disable
Disable
None
None
Enable
Enable
Enable
151
