CipherLab RS30 Reference Manual page 169

Composite CC-C
Composite CC-C
Composite TLC 39
Composite TLC 39
Composite General Preference
UPC Composite Mode
GS1-128 Emulation
Mode
GS1 DATABAR
GS1 DataBar-14
GS1 DataBar-14
Convert to UPC/EAN
GS1 DataBar Limited
GS1 DataBar Limited
Convert to UPC/EAN
Security Level
GS1 DataBar Expanded
GS1 DataBar Expanded Switch to enable GS1 DataBar Expanded decoding.
Separator Character
KOREAN 3 OF 5
Switch to enable Composite CC-C decoding.
Switch to enable Composite TLC 39 decoding.
UPC barcodes can be "linked" with a 2D barcode during
transmission as if they were one barcode.
UPC Never Linked
Transmit UPC barcodes regardless of whether a 2D
barcode is detected.
UPC Always Linked
Transmit UPC barcodes and the 2D portion. If the 2D
portion is not detected, the UPC barcode will not be
transmitted.
CC-A/B or CC-C must be enabled.
Auto-discriminate
Transmit UPC barcodes as well as the 2D portion if
present.
Sets GS1-128 emulation mode for UCC/EAN Composite
Codes.
Switch to enable GS1 DataBar-14 decoding.
Strips the leading '010' of GS1 DataBar and converts the
barcode to EAN-13.
Switch to enable GS1 DataBar Limited decoding.
Strips the leading '010' of GS1 DataBar Limited and converts
the barcode to EAN-13.
There are setting options from Level 1 to 4.
Enable the function code character separator, which is used
to separate data fields of variable length and application
identifiers of subsequent data fields in concatenated data
strings.
2D Imager (SE4500DL)
Enable
Enable
Disable
Disable
UPC always
Linked
Disable
Enable
Enable
Disable
Enable
Enable
Disable
Level 3
Enable
Enable
None
155
