CipherLab RS30 Reference Manual page 122

RS30 Mobile Computer
1D LASER READER SETTINGS
Setting
Decode Timeout
Redundancy Level
Scan Angle
Scan Mode
Timeout Between
Symbols
Addon Redundancy
108
Description
Sets the maximum time for the decoding process during a scan.
Configurable between 1 sec to 9 sec.
Sets how many successful readings should be done before
linear barcodes such as Codabar, MSI, and Interleaved 2 of 5
can be decoded. Levels 1 to 4 available.
The readings needed for each level are as follows:
Level Description
Level 1 The following
successfully
decoded: Codabar, MSI, Industrial 25
(Discrete 25), Interleaved 25.
Level 2 All barcodes must be successfully read
twice before being decoded.
Level 3 All barcodes must be successfully read
twice before being decoded, except for the
following which must be read three times:
MSI,
Interleaved 25.
Level 4 All barcodes must be successfully read
three times before being decoded.
Sets the scan angle for laser scan engine.
Wide Angle: 47° (Extended range laser reader is fixed at Wide Angle)
Narrow Angle: 35°
Sets the reader's scanning behavior. Options available are
Continuous and Level modes.
Continuous: Used for continuous reading of barcodes. The scan engine
remains on when this mode is activated.
Level: Reads a barcode when the trigger is pressed.
Sets the time for the barcode reader to resurrect its ability to
once more decode the barcode it just decoded.
Only applied in Continuous mode
Functions when "auto-discriminate" is applied for UPC/EAN
addons. Decides the number of times of supplemental decoding
of the same barcode in order to count as a valid read.
Configurable between 2 and 30.
barcodes
read twice before
Industrial 25 (Discrete
Reference Manual
Default
3 sec
Level 1
must be
being
25),
Wide
Angle
Level
1 sec
10
