9300 Mobile Computer

INSTALLING BATTERY

For shipping and storage purposes, the mobile computer and the main battery are saved
in separate packages.
Note: Any improper handling may reduce the battery life. Release the hand strap from
the mobile computer before installing the battery.
1) Hold the mobile computer still and slide the release button to the right.
2) Hold tight to remove the battery cover.
3) Insert the battery pack into the battery compartment at a proper angle (30°~45°) so
that the metal contacts on the battery are met with the charging contacts inside the
compartment.
4) Fit the battery snugly into the compartment.
5) Place the battery cover back onto the mobile computer until it clicks into place.
6) If the battery is charged, the mobile computer turns on. If the mobile computer does
not turn on, charge the battery.
Figure 4: Installing the Main Battery
8
Reference Manual
