1.1.2. INSTALLING SIM CARD, SAM CARD AND MEMORY CARD

The RS30 Mobile Computer is equipped with two SIM card slots, one SAM card slot and one
memory card slot.
To insert the cards:
1) Remove the battery cover as described in steps 1-3 of
2) Insert the cards into their respective slots according to the directions indicated. Push the
cards to lock them in.
Top Left
SIM2 card slot
(GSM only)
Bottom Left
SAM card slot
The SIM 1 slot (on the right) supports both 2G and 3G networks, while the SIM 2 slot (on
the left) supports only 2G networks. See
2G and 3G networks.
3) Replace the battery cover and push the battery lock back to the lock position.
Remove Cards
1) Remove the battery cover as described in steps 1-3 of
2) Push the SIM cards, SAM card and SD card to eject them from their slots.
3) Replace the battery cover and push the battery lock back to the lock position.
Installing
Data Connection Settings
Installing
Chapter 1 Quick Start
Battery.
Top Right
SIM1 card slot
(GSM & WCDMA)
Bottom Right
SD card slot
for how to configure
Battery.
