Appendix 2
Media Specifications

Paper Roll Size

56
Core
Diameters:
Width:
The web must be attached to the core in such a way that the printer
can pull the end of the web free.
Roll
Max. diameter:
Max. width:
Min. width:
Max. web thickness: 175µm (0.007")
The maximum recommended web thickness is 175µm. A thicker
web may be used, but print quality will be reduced. Web stiffness is
also important and must be balanced against web thickness to main-
tain print quality.
Paper rolls should be wound with the printable side facing outwards.
Intermec EasyCoder E4 LinerLess – Installation & Operation Ed. 1
38 mm (1.5") (hanger in bottom position)
76.2 mm (3") (hanger in top position)
Must not protrude outside the web.
152 mm (6")
114 mm (4.5")
25.4 mm (1")
