Chapter 4 Programming
Command List, cont'd.
Instruction
NASCD
NORIMAGE (NI)
PRBAR (PB)
PRBOX (PX)
PRESCALE (PS)
PRIMAGE (PM)
PRINT (?)
PRINT KEY ON/OFF
PRINTFEED (PF)
PRLINE (PL)
PRPOS (PP)
PRSTAT
PRTXT (PT)
REBOOT
26
Purpose and Syntax
Selects a mapping method for double byte character set fonts.
NASCD "<filename of character set>"
Returns to normal printing after INVIMAGE printing.
NORIMAGE|NI
Prints a bar code.
PRBAR|PB <input data>[;<input data>]
Prints a box.
PRBOX|PX <height>,<width>,<line thickness>
Scales the characters listed in the accompanying text string using the
current font settings. Prescaled characters are saved in "ram:".
PRESCALE|PS "<string>"
Prints an image stored in the printer's memory.
PRIMAGE|PM "<image name>"
Prints data to the standard OUT channel.
PRINT|? "<input data>"[;"<input data>"]
Enables/disables printing of the current label when the Feed key is
pressed.
PRINT KEY ON|OFF
Prints and feeds out one or a specified number of labels, tickets, tags or
portions of strip, according to the printer's setup.
PRINTFEED|PF [<batch size>]
Draws a solid rectangle.
PRLINE|PL <length>,<line thickness>
Specifes the insertion point for a line of text, a bar code, an image, a box
or a line.
PRPOS|PP <x-coordinate>,<y-coordinate>
Returns the printer's current status.
(PRSTAT AND <parameter>)
Provides the input data for a text field, i.e. a line of text.
PRTXT[PT "<input data>"[;"<input data>"]
Restarts the printer.
REBOOT
