Communication
Setup, cont'd.
In the setup string examples,
underscored space characters
(as in "CHAR_LENGTH") in-
dicate mandatory space charac-
ters in the command line.
Quotation marks (" ") are ASCII
34 dec.
Intermec EasyCoder E4 LinerLess – Installation & Operation Ed. 1
By default, the serial port is set for 9600 baud, No parity, 8 data
bits, 1 stop bit, XON/XOFF disabled both ways. Note that as soon
as a parameter is changed, you must change the setup of the host the
same way, or the communication will be lost.
• Baudrate
This setting controls the speed of the serial communication
between printer and host (1 baud = 1 data bit per second). There
are 8 options:
300 600 1200 2400 4800
Setup string, example:
SETUP " SER-COM,UART1,BAUDRATE,9600"
• Parity
This setting controls how the software will check for errors in the
serial communication. There are 5 options:
None Even Odd Mark Space
Setup string, example:
SETUP " SER-COM,UART1,PARITY,NONE"
• Character Length
This setting controls how many bits are used to specify a character
in the serial communication. There are two options:
7 Characters ASCII 0 – 127 dec. can be transmitted
8 Characters ASCII 0 – 256 dec. can be transmitted
Setup string, example:
SETUP " SER-COM,UART1,CHAR_LENGTH,7"
• Stop Bits
This setting controls how many bits are used to specify a stop
character in the serial communication. There are two options:
1 or 2
Setup string, example:
SETUP " SER-COM,UART1,STOPBITS,1"
Chapter 5 Printer Setup
9600 19200 38400
↵
↵
↵
↵
