Pinning of RJ 45 Jacks

U , a/b, Sensor,
pn
Actor
S
0
S
2M
10Base-T

Switches on Front Panel

The bus termination resistors
■
for all the S
switchable.
Please note: In the factory set-
ting on delivery, the switches are
open, i.e. the termination resistors are
not switched on.
The internal S
■
at one end (NT) by the
OpenCom 110/120 Rack with
100 Ω termination resistors; the
DIP switches below the respec-
tive RJ jacks are "on" (i.e. closed)
in the upper position.
Please note: Both S
switches must be in the same posi-
tion.
The S
■
ends with 100 Ω termination re-
sistors; the DIP switches below
the respective RJ jacks are "off"
(i.e. open) in the lower position.
44
Mounting the OpenCom 110/120 Rack InfoCom System
PIN 4-5
PIN 4-5, 3-6
PIN 4-5, 1-2
PIN 1-2, 3-6
internal ports are
0
bus is terminated
0
bus
0
bus is terminated at both
0
The DIP switches on a/b port 1
■
are normally "on" (i.e. closed) in
the upper position. If the device
is set for the entrance intercom
port, the switches must be in the
lower position ("off").

Scope of Delivery

Adapter cable RJ 45 - RS 232 for
■
V.24/COM interface
Screws for rack mounting
■
For complete installation the
■
country-specific installation
package is necessary. It contains
the power cord, a complete set
of manuals and a CD-ROM.
Note: Note for the DeTeWe in-
staller: Please download and install
the latest released software from our
Web site/partnership area.
