Accessories and Adapters

The OpenPhone 63 and
OpenPhone 65 system telephones
have one or two slots on the rear for
various adapters and other accesso-
ries. Further information on install-
ing and operating these add-ons can
be found in the "OpenPhone 61, 63,
65" user guide under "Add-ons (with
& without an Adapter)".
In the following you will find techni-
cal details on the add-ons and a list
of compatible accessories.
U Adapter
pn
The U adapter is an adapter with a
pn
U port for connecting another
pn
OpenPhone 61, 63, 65 system tele-
phone and a socket for an extra
plug-in power supply.
Weight: 70 g
Dimensions: 73 x 60 x 30 mm
Power consumption: max. 195 mW
Cable length: max. 30 m
Please note: The U
may be used only for connecting the
system terminals listed above. The
U extension cable must not exceed
pn
30 m in length and must not be used
outdoors.
adapter
pn
Note: An extra plug-in power sup-
ply is required to operate combina-
tions of equipment with a power con-
sumption that exceeds the power
output of the U ports.
pn

a/b Adapter

You can use an a/b adapter to con-
nect analogue terminals to the
OpenPhone 63 and OpenPhone 65
system telephones.
Connecting an a/b adapter will re-
sult in exceeding the feed perform-
ance of the U port, regardless of
pn
the range. Therefore a plug-in power
supply must be additionally con-
nected to the a/b adapter.
Note: Please use the plug-in power
supply with the product code
4505759. The plug-in power supply
for use in the UK has the product code
4510694.
Weight: 70g
Dimensions: 73 x 60 x 30 mm
Power consumption: max. 160 mW
Cable length: max. 3 m
