LAN
Question: It is not possible to es-
tablish a network connection with
the OpenCom 100.
Check whether the LEDs for the hub
and the PC's network card are indi-
cating a connection.
Remove the labelling strip. Check
the LEDs for the LAN functions of the
OpenCom 100. The upper green LAN
LED at the top indicates whether the
network cable has been properly
connected. The lower red LAN LED at
the bottom indicates whether there
is any network traffic on the line.
To check whether there is a network
connection with your OpenCom 100,
enter the "ping IP address" com-
mand in "Run" in the Windows Start
menu (e.g. ping 192.168.99.254).
Question: How can I determine
the IP address of the
OpenCom 100?
To find out what the IP address is,
enter the code number
* 1 8 2
nected system telephones.
The code-number procedure
* 1 8 3
work mask.
124
LAN
on one of the con-
also displays the net-
Question: The network connec-
tion is functioning, but nothing is
displayed in the browser.
Enter the complete IP address of the
OpenCom 100 along with the proto-
col identifier, for example http://
192.168.99.254/.
Check whether the browser has
been configured for connection
through a proxy server. If so, deacti-
vate the "Connect through proxy
server" setting.
Question: You have just config-
ured the OpenCom 100 via the net-
work. Why is it not possible now to
establish a remote data transfer
network connection?
The network card and the communi-
cation (remote data transfer)
adapter cannot be run with the
same routing setting. Deactivate the
network card before connecting via
the dial-up network.
Question: Our network has grown
over time, with several segments
connected by one central router.
How can PCs from all segments be
connected with the OpenCom 100?
In the Configurator, use the LAN
setting in ISP to specify the central
router as the default gateway. If nec-
essary, deactivate any filter rules de-
Frequently Asked Questions
