DND: "On" if the extension is set to Do Not Disturb
CHKO: "In" if the extension is checked in (see page 15) or "Out" if checked out
LDIS: "On" if the extension is allowed to make long-distance calls
EXTS: "On" if the extension is allowed to make extension-to-extension calls
LOCL: "On" if the extension is allowed to make local calls

A23 Active Stations Report

Use this command to list all stations (extensions) currently in use. The report will show the hardware sta-
tion port number, the extension number, and whether or not the connection is normal or in a problem state.
The report displays as:
Date/time 06/15/99 07:35
Sta# Ext# Norm/Prob
017 101 N
026 110 N
"N" in the problem column indicates the extension is in its normal state; a "P" indicates either a wiring
problem or a possible PhoneSuite software problem. Contact your PhoneSuite dealer for advice.

A24 View PhoneSuite Main Board Software Version

This command is used to display the version number of the PhoneSuite Main Board Software. To view this,
dial A-2-4 on the console keypad. The display will read:
Softw Vers V.VVV
Reset Count=###
Where V.VVV is the software version number and ### is a 3-digit number that indicates how many times
PhoneSuite has been powered up from an unpowered state. This information will display for a few seconds,
and then the display will return to normal. To exit this function before it times out, press "D."

A25 Request Property Management System Database Dump (Model 112e only)

This rarely-used command requests information from a Property Management System (PMS) that is con-
nected to a PhoneSuite Model 112e. This command is not available in PhoneSuite Model 64. Normally,
PhoneSuite and the PMS synchronize their data automatically. However, if PhoneSuite is powered on after
having been off for a considerable amount of time, it may be desirable to request a PMS Database Dump to
speed up this process. To do this, dial A-2-5 on the console keypad. The display will show:
DATA LOAD/CHANGE
SUCCESSFUL!
and will then return to idle.
®
PhoneSuite Console User's Manual rev. 081106
37
