Operating the device
5.4.

DLT-V83 front keys with resistive touchscreen

5.4.1.

Overview of the operating elements on the device front

Fig. 5.2: Example: DLT-V8312 version with 26 front keys

Front keys:
- Turn on/off
- Display brighter
- Display darker
- Backlighting
on/off
- Touch on, off
LEDs:
- Temperature
- Flash drive
- Supply voltage
Page 18 of 122
Front keys:
Shift, function keys F1 to F12
Numbers 0 bis 9, point, backspace
DLT-V83 Series Manual V1.50
Front keys:
- Arrow keys
- Pg Up, Pg Dn
- Home
- End
- Special keys
S1, S2
- Esc
- Enter
