2. Installation

The Atlas250 multimedia router is designed to be both a desktop and a rack device. In either case, in
order to accomplish correct installation, please follow the recommendations given below:
BEFORE CONNECTING THE DEVICE PLEASE READ THE FOLLOWING
INSTRUCTIONS CAREFULLY.

2.1. General installation conditions

Workplace Conditions
Bear in mind the following recommendations:
1. Excessive cold and heat should be avoided, as should humidity and dust. Direct
exposure to sunlight should be avoided as well as other heat sources. The device should
not be placed amongst papers, magazines or other elements that could hinder natural air
circulation.
2. The device should not be placed very close to strong electromagnetic fields such as
speakers, engines, etc.
3. Knocks and/or strong vibrations should be avoided during transport, operation and
storage.
Power supply
The Atlas250 communications device does not require special conditions as regards voltage stability
or protection against power malfunctions as it is already protected.
To avoid electric shocks, residual current circulation and other unwanted effects, also affecting data
communications, the following is recommended:
• It is highly recommended that all interconnected data devices be plugged to THE
SAME GROUNDED POWER OUTLET, which should at the same time be of good
quality (lower than 10ohms).
• Whether the workplace is provided with an uninterrupted power supply system
(UPS), regulated supply or it is independent from the rest (such as lighting, etc.); it
is highly recommended that all data devices should be connected to the same power
source. This will avoid operating and premature aging problems of drivers and
other components.
WARNING: Electric supply current, telephone and communication cables are dangerous. To
prevent electric shock while installing, moving or opening the device covers, cables should
be disconnected and connected as follows.
To connect the Atlas250
•
Make sure that the device power supply
switch is OFF
•
Connect all the data cables.
•
Connect the power supply cable.
•
Switch on the device.
ATLAS 250 – Installation Manual
3
To disconnect the Atlas250
•
Switch off the device.
•
Disconnect the power supply cable
•
Disconnect the data cables.
