5.2

The repetition frequency is transmitted via the System Bus.

Note: Only the parameterization required for realizing the electronic gear are de-

5.2.1

If a frequency inverter is configured as Master of the electronic gear, the following

settings can be made for the transmission of the repetition frequency via the System

Bus.

•

Note: The parameters of the System Bus (e.g. TxPDO's for transmission of the data)

09/08

Adjustment Options

scribed here. For operation of the System Bus, further settings are required.

These are described in the operating instructions of the expansion modules

with System Bus.

If not yet done after commissioning, select a configuration for parameter

ration

30, e.g. Configuration "210 – speed-controlled field-oriented control" for

speed control of the Master drive with speed sensor feedback. Depending on the

application, another configuration can be selected, too.

If a configuration with speed sensor feedback is selected, check if the speed sen-

sor monitoring is switched on. Speed sensor monitoring is activated by default. By

selecting operation mode "2 – Error" for parameter

switch on the speed sensor monitoring.

Select a source for a Transmit-PDO of data type long, e.g. select signal source

"80 - Speed Sensor 1" via parameter

repetition frequency to the Slave.

are only available if the file sysbus.xpi is loaded in the software VPlus.

Application Manual Electronic Gear

Operation Mode

TxPDO1 Long1

954 for transmission of the

Configu-

760, you can
