BONFIGLIOLI ACTIVE CUBE Applications Manual page 29

Overview of Parameter Setting Examples:
Master Settings
30
420 Acceleration (Clockwise)
421 Deceleration (Clockwise)
490 Operation Mode (of speed sensor 1)
491 Division marks (of speed sensor 1)
546 Operation Mode Repetition Frequency 101 – Frequency speed sensor 1 wo.
760 Operation Mode (of speed sensor
766 Actual speed source
Slave Settings
30
125 El. Gear Reference Frequency
147 Position Reference Value
148 Position Actual Value
420 Acceleration (Clockwise)
421 Deceleration (Clockwise)
490 Operation Mode (of speed sensor 1)
491 Division marks (of speed sensor 1)
493 Operation Mode (of speed sensor 2)
494 Division marks (of speed sensor 2)
495 Operation Mode Level (of speed sen-
685 Gear Factor Numerator
686 Gear Factor Denominator
689 Operation Mode (of electronic gear)
696 Amplification Position Controller
697 Lim. Position Deviation
698 Lim. Position Controller
766 Actual speed source
09/08
09/08
Parameter
Configuration
monitoring)
Configuration
sor 2)
This parameter is available after loading of a configuration file, e.g. swc215.xpi.
Application Manual Electronic Gear
Application Manual Electronic Gear
Setting/Selection
210 – speed-controlled field oriented
control
5 Hz/s
5 Hz/s
4 – Quadruple Evaluation
Division marks of the master speed
sensor
corr.
2 – Error
1 – Speed sensor 1
215 – speed-controlled field-oriented
control with electronic gear
81 – Freq. Speed Sensor 2
83 – Position Speed Sensor 2
82 – Position Speed Sensor 1
10 Hz/s
10 Hz/s
4 – Quadruple Evaluation
Division marks of the slave speed sen-
sor
4 – Quadruple Evaluation
Division marks of the master speed
sensor
0 – push-pull
1
1
11 – Fixed with position controller
10.00%
99 999°
3.00 Hz
1 – Speed sensor 1
27
27
