Reference Value And Actual Value Input - BONFIGLIOLI ACTIVE CUBE Applications Manual

4.5
The following inputs of the slave frequency inverter can be used for reference fre-
quency transmission from master to slave. The actual value input receives the actual
speed from the slave speed sensor.
Configuration
Configuration
Configuration
(1)
(2)
(3)
Parameterisation of the inputs:
Speed sensor 1 input:
Speed sensor 2 input
Repetition frequency input:
(1)
The factory settings of electronic gear configurations provide reference value inputs. If
other inputs are required , for example speed sensor 2 input of an expansion module,
loading of XPI files to the software VPlus is necessary. These files include additional
parameters. For instance file swc215.xpi must be loaded, if configuration 215 is ad-
justed.
16
16

Reference value and actual value input

Frequency inverter without expansion module
Reference value input
115 Speed sensor 1
116 Repetition frequency input
215
Repetition frequency input
216
Speed sensor 1
415
Repetition frequency input
Frequency inverter with expansion module EM-ENC or EM-IO
Reference value input
Speed sensor 1
115
Speed sensor 2
116
Repetition frequency input
Repetition frequency input
215
Speed sensor 1
216
Speed sensor 2
Speed sensor 1
415 Speed sensor 2
Repetition frequency input
Frequency inverter with expansion module EM-RES
Reference value input
515 Speed sensor 1
516 Repetition frequency input
Factory setting.
Additional Note for Configuration 116 and 216: The factory setting "Speed sensor 1" is only
set to track A.
Parameterisation of the repetition frequency input is not possible, if an expansion module EM-
ENC-01 is connected. Use speed sensor 1 input or speed sensor 2 input.
Communication modules CM are not taken into consideration by this distinction.
