General Information about the Documentation
This manual complements the configurations described in the operating instructions
and the Quick Start Guide of the ACU 201 and ACU 401 frequency inverters. Configu-
rations 115, 215, 415 and 515 additionally include the functions of an electronic gear
with position controller. Configurations 116, 216 and 516 extend the functionality by
the electronic gear with index controller.
For better clarity, the documentation is structured according to the customer-specific
requirements made on the frequency inverter.
Quick Start Guide
The Quick Start Guide describes the basic steps required for mechanical and electrical
installation of the frequency inverter. The guided commissioning supports you in the
selection of necessary parameters and the software configuration of the frequency
inverter.
Operating Instructions
The Operating Instructions describe and document all functions of the frequency in-
verter. The parameters required for adapting the frequency inverter to specific appli-
cations as well as the wide range of additional functions are described in detail.
Application Manual
The Application Manual contains additional information facilitating the installation and
commissioning of the frequency inverter, i.e. information on the different issues relat-
ing to the specific application realized by the frequency inverter.
Installation Instructions
Complementing the Quick Start Guide and the Operating Instructions, the Installation
Instructions provide information on how to install and use the additional/optional
components.
If you need a copy of the documentation or additional information, contact your local
representative of BONFIGLIOLI.
The following pictograms and signal words are used in the documentation:
Danger!
Danger refers to an immediate threat. Non-compliance with the precaution described
will result in death, serious injury or material damage.
Warning!
Warning refers to a possible threat. Non-compliance with the warning may result in
death, serious injury or material damage.
Caution!
Caution refers to an immediate hazard. Damage to people or property can be the
result.
Attention!
Attention and the related text refer to a possible behavior or an undesired condition
which can occur during operation.
Note
Note marks information which facilitates handling for you and supplements the corre-
sponding part of the documentation.
