This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to
service or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.
R32 REFRIGERANT
– This Air Conditioner contains and operates with refrigerant R32.
THIS PRODUCT MUST ONLY BE INSTALLED OR SERVICED BY QUALIFIED PERSONNEL.
Refer to Commonwealth, State, Territory and local legislation, regulations, codes, installation & operation manuals, before the
installation, maintenance and/or service of this product.
POWE R
T IME R
+8/1 0°C na noe /O DOR CLEANUP
COOL
DRY
HEAT
AUTO
TEMP
OFF
+8/10°C
INFO
HEAT
WARNING
CAUTION
Indoor Unit
CS-VZ9SKE
CS-VZ12SKE
Order No: RAC1511002CE
Outdoor Unit
CU-VZ9SKE
CU-VZ12SKE
Destination
Europe
© Panasonic Corporation 2015.
