Operating Instructions
Air Conditioner
Model No.
Indoor Unit
CS-VZ9SKE
CS-VZ12SKE
nanoe/ODOR CLEANUP
POWER
TIMER
+8/10°C
Outdoor Unit
CU-VZ9SKE
CU-VZ12SKE
Operating Instructions
Air Conditioner
Thank you for purchasing Panasonic Air Conditioner.
Installation instructions attached.
Before operating the unit, read these operating
instructions thoroughly and keep them for future
reference.
Comment utiliser l'appareil
Climatiseur
Nous vous remercions d'avoir porté votre choix sur un
climatiseur Panasonic.
Instructions d'installation jointes.
Avant d'utiliser l'appareil, lisez ce mode d'emploi dans
son intégralité et conservez-le pour toute référence
ultérieure.
Instrucciones de funcionamiento
Climatizador de aire
Muchas gracias por elegir una unidad de aire
acondicionado Panasonic.
Incluye instrucciones de instalación.
Antes de utilizar la unidad, sírvase leer atentamente
estas instrucciones de funcionamiento y
conservarlas como futuro elemento de consulta.
Bedienungsanleitung
Klimagerät
Wir danken Ihnen für den Kauf Ihres Panasonic-
Klimageräts.
Die Montageanleitung liegt dem Gerät bei.
Bevor Sie das Gerät in Betrieb nehmen, lesen Sie bitte
diese Bedienungsanleitung aufmerksam durch
und bewahren Sie sie für die künftige Verwendung auf.
Istruzioni di funzionamento
Condizionatore d'aria
Grazie per aver acquistato un climatizzatore Panasonic.
Istruzioni d'installazione allegate.
Prima di utilizzare l'unità si prega di leggere
attentamente le istruzioni e di conservare questo
opuscolo per potervi fare riferimento in futuro.
Handleiding
Airconditioner
Hartelijk dank voor de aanschaf van de
Panasonicairconditioner.
Installatie-instructies bijgevoegd.
Lees voor u het apparaat gebruikt deze
gebruiksinstructies grondig en bewaar ze
voor toekomstig gebruik.
2-15
16-29
30-43
44-57
58-71
72-85
ACXF55-00860
