Administrator's Guide - SoundPoint

The application log file is uploaded periodically or when the local copy reaches a pre-
determined size.
As an additional diagnostic tool, both log files can be uploaded on demand to the boot
server by pressing and holding the following keys until a confirmation tone is heard or
for about three seconds:
SoundPoint
SoundPoint
502, 600, and 601:
SoundStation
Log files uploaded in this manner are named:
• <Ethernet address>-now-boot.log
• <Ethernet address>-now-app.log
Central
(boot
server)
Local

4.5 Audio Quality Issues and VLANs

The phone contains both network layer and Ethernet layer support for prioritizing
voice and signaling traffic over the network. Quality of Service (QoS) parameters
include IP type-of-service (TOS) bits, and Ethernet IEEE 802.1p user priority. These
can be set on a per-protocol basis. The phone also supports RTCP per RFC 1889.

4.5.1 IP TOS

The "type of service" field in an IP packet header consists of four TOS bits and a 3-bit
precedence field. Each TOS bit can be set to either 0 or 1. The precedence field can be
®
IP / SoundStation
® Line1, Line2, Arrow Up, Arrow Down
IP 300 and 301:
® The four arrow keys
IP 430, 500,
® Menu, Exit, Off-hook/Hands-free, Redial
IP 4000:
Configuration file:
sip.cfg
Configuration file:
<Ethernet
address>.cfg
Web Server
(if enabled)
Local Phone User
Interface
Copyright © 2006 Polycom, Inc.
®
IP
Specify a multitude of event logging settings.
• For more information, refer to 4.6.1.19 Event Logging
<logging/> on page 137.
Specify different directory to use for log files if desired.
• For more information, refer to 2.2.2.1.1.1 Master Con-
figuration Files on page 13.
Specify a multitude of event logging settings.
Navigate to: http://<phoneIPAddress>/coreConf.htm#lo
None.
Optimization
81
