2.2.1.3 Local User Interface Setup Menus

Access to Network Configuration Menu
Phase 1: bootROM
Phase 2: application
Phone network configuration parameters may be edited by means of:
• Main menu. Refer to 2.2.1.3.1 Main Menu on page 8.
• DHCP submenu. Refer to 2.2.1.3.2 DHCP Menu on page 9.
• Server submenu. Refer to 2.2.1.3.3 Server Menu on page 11.
• Ethernet submenu. Refer to 2.2.1.3.4 Ethernet Menu on page 12.
Use the soft keys, the arrow keys, the Sel/ , and the Del/X keys to make changes.
Certain parameters are read-only due to the value of other parameters. For example, if
the DHCP Client parameter is enabled, the Phone IP Addr and Subnet Mask parame-
ters are dimmed or not visible since these are guaranteed to be supplied by the DHCP
server (mandatory DHCP parameters) and the statically assigned IP address and sub-
net mask will never be used in this configuration.
2.2.1.3.1 Main Menu
Configuration parameters that may be edited on the main setup menu are described in
the table below:
Name
DHCP Client
DHCP Menu
Phone IP Address
Subnet Mask
8
® ®
IP / SoundStation
The network configuration menu is accessible during the
auto-boot countdown of the bootROM phase of operation.
SETUP
Press the
The network configuration menu is accessible from the
main menu. Navigate to Menu>Settings>Advanced>Admin
Settings>Network Configuration. Advanced Settings are
locked by default. Enter the administrator password to
unlock. Note that the factory default password is 456.
a
Possible Values
Enabled, Disabled
dotted-decimal IP
address
dotted-decimal subnet
mask
Copyright © 2006 Polycom, Inc.
IP
soft key to launch the main menu.
Description
If enabled, DHCP will be used to obtain the
parameters discussed in 2.2.1.1 DHCP or Man-
ual TCP/IP Setup on page 5.
Refer to 2.2.1.3.2 DHCP Menu on page 9.
Note: Disabled when DHCP client is disabled.
Phone's IP address.
Note: Disabled when DHCP client is enabled.
Phone's subnet mask.
Note: Disabled when DHCP client is enabled.
