DISCONNECTING/CONNECTING THE CABLES AND HOSE (SHORT HANDLE)

Step
Engine oil drain
1
Throttle cable
2
Oil level gauge
3
Water hose
POWER UNIT
Job/Part
Q'ty
Refer to "REPLACING THE ENGINE OIL" on
page 3-14.
2
1
1
For installation, reverse the removal
procedure.
5-14
Remarks
